An embeddable runtime dashboard for Squid Mesh.

SquidSonar adds a read-only Phoenix LiveView dashboard to applications that run Squid Mesh workflows. Mount it inside an existing Phoenix app to inspect recent runs, filter by status, search runtime metadata, and open detail pages that show the workflow graph, diagnosis, attempt counts, history counts, and last error information.

Current Shape

SquidSonar is distributed as an embeddable library, not a standalone service. A host Phoenix application owns authentication, authorization, deployment, endpoint configuration, and the Squid Mesh runtime. SquidSonar contributes the router macro, LiveViews, static assets, and a small read boundary over Squid Mesh public APIs.

The current UI includes:

• Recent workflow runs sorted by update time
• Status counts and filters
• Search across workflow, trigger, step, status, and run ID
• Page size controls and pagination
• Run detail pages with diagnosis, history counts, last error, and workflow graph visualization
• Step attempt counts on run detail pages
• Light, dark, and system theme controls
• Embedded CSS and JavaScript served by the library

Requirements

• Elixir 1.17 or later
• Phoenix 1.8
• Phoenix LiveView 1.1
• A host application with Squid Mesh installed and configured

Installation

Add SquidSonar to the host application's dependencies:

def deps do
  [
    {:squid_sonar, "~> 0.1.0"}
  ]
end

Then fetch dependencies:

mix deps.get

Mounting

Import SquidSonar.Router in the host router and mount the dashboard under the path that makes sense for the application:

defmodule MyAppWeb.Router do
  use MyAppWeb, :router
  use SquidSonar.Router

  scope "/ops" do
    pipe_through [:browser, :require_authenticated_user]

    squid_sonar "/sonar", otp_app: :my_app
  end
end

Visit /ops/sonar to open the dashboard.

SquidSonar accepts a few route-level options:

squid_sonar "/sonar",
  otp_app: :my_app,
  as: :runtime_sonar,
  socket_path: "/live",
  transport: "websocket"

transport can be "websocket" or "longpoll".

Security

SquidSonar intentionally does not ship its own authentication layer. Protect the mounted route with the same browser pipeline, session handling, and authorization rules used for the rest of the host application's operator surface.

The current dashboard is read-only. It displays runtime data returned by Squid Mesh, including workflow names, run IDs, step names, statuses, diagnostic signals, and selected error metadata. Treat the mounted dashboard as operational visibility and expose it only to trusted users.

Example App

The repository includes a Phoenix example app at examples/example_app. It mounts SquidSonar at /sonar and seeds real Squid Mesh workflows that produce completed, failed, retrying, and paused runs.

cd examples/example_app
mix deps.get
mix ecto.create
mix ecto.migrate
mix example.seed
mix phx.server

Open http://localhost:4010/sonar after the server starts.

Library Modules

• SquidSonar.Router mounts the embedded dashboard routes.
• SquidSonar.Runs is the read boundary over Squid Mesh run APIs.
• SquidSonar.Dashboard builds the filtered, paginated dashboard snapshot.
• SquidSonar.Runs.WorkflowGraph turns workflow definitions and persisted run state into a display graph.
• SquidSonarWeb.* contains the embedded LiveViews, components, layout, hooks, and asset controller.

License

Apache-2.0
