Roadrunner

Pure-Erlang HTTP/1.1 + HTTP/2 + WebSocket server for OTP 29+. Built for low tail latency at sustained load. Beep beep.

Roadrunner is the HTTP backbone of the arizona-framework. Strict RFC 9110 / 9112 / 9113 parsing, with strict 100 % h2spec (HTTP/2 conformance) and strict 100 % Autobahn fuzzingclient (WebSocket, no exclusions). The user-facing API is a handler behaviour, request/response accessors, listener controls, and a handful of opt-in helpers (cookies, qs, multipart, SSE, WebSocket). Modern OTP idioms throughout, with predictable per-connection lifecycle observability.

⚠️ Requirements

Requires OTP 29 or newer.

🚧 Status

Roadrunner is in 0.x. The core is functional and covered by tests, but the API may change between minor versions. Pin an exact version in your deps (e.g. {roadrunner, "0.1.0"}) if you need stability across upgrades.

✅ Conformance

Eunit + Common Test (incl. PropEr) suites with 100 % line coverage, dialyzer-clean, h2spec strict 100 %, Autobahn fuzzingclient strict 100 % across the full WebSocket matrix (no exclusions). HTTP/1.1 parsers stress-tested against the llhttp test corpus and the canonical PortSwigger request-smuggling vectors.

Standards conformance:

• HTTP/1.1: RFC 9110 (semantics) + RFC 9112 (syntax).
• HTTP/2: RFC 9113 (frames + multiplexing) + RFC 7541 (HPACK). Opt-in per listener via protocols => [http1, http2] (or [http2] for h2c prior-knowledge on plain TCP). Conformance harness: scripts/h2spec.sh (drives h2spec).
• Content-Encoding (RFC 9110 §8.4.1): gzip + deflate with qvalue-aware Accept-Encoding negotiation (RFC 9110 §12.5.3), works unchanged over HTTP/2.
• WebSocket: RFC 6455. Conformance harness: scripts/autobahn.escript (drives the Autobahn|Testsuite fuzzingclient).
• WebSocket compression: RFC 7692 permessage-deflate, including *_max_window_bits and *_no_context_takeover.

Performance at a glance

Median req/s over HTTP/1.1 on a 12th-gen i9-12900HX, 50 clients, 5 s warmup + 5 s measure, loopback. HTTP/2 numbers, p50 / p99 percentiles, and memory shape sit in docs/bench_results.md and docs/comparison.md.

Bold = fastest in row. — means the elli fixture doesn't expose that workload (no router, no gzip middleware, no WebSocket, no streaming-POST endpoint). On simple GETs and small POSTs Roadrunner and elli are within the bench's ~15 % variance band on those rows; the comparison doc has the full honest framing.

Tail latency at sustained load

Open-loop, Coordinated-Omission-corrected (wrk2, hello, 8 threads, 50 connections, 3-run median): Roadrunner sustains 270 k req/s at p50 1.06 ms, p99 2.26 ms, p99.99 3.34 ms. Full per-scenario matrix with all four rate-points per server in docs/wrk2_results.md.

The throughput numbers above are from scripts/bench.escript (closed-loop); the comparison doc has the full methodology breakdown.

Comparison

If your workload needs a feature, the server has to ship it. — means achievable in user code but no helper / option built in; ✗ means out of scope for that server.

Quickstart

Add to rebar.config:

{deps, [
    {roadrunner, "0.1.0"}
]}.

Write a handler — the third route element is per-route state, threaded to the handler via roadrunner_req:state/1:

-module(hello_handler).
-behaviour(roadrunner_handler).
-export([handle/1]).

handle(Req) ->
    #{greeting := Greeting} = roadrunner_req:state(Req),
    {roadrunner_resp:text(200, <<Greeting/binary, ", roadrunner!">>), Req}.

Boot a listener:

1> application:ensure_all_started(roadrunner).
2> roadrunner:start_listener(my_listener, #{
       port => 8080,
       routes => [{~"/", hello_handler, #{greeting => ~"hello"}}]
   }).

$ curl -i localhost:8080
HTTP/1.1 200 OK
content-type: text/plain; charset=utf-8
content-length: 18

hello, roadrunner!

For HTTP/2 over TLS, add a cert and list both protocols. ALPN is derived from protocols automatically:

3> roadrunner:start_listener(my_tls_listener, #{
       port => 8443,
       protocols => [http1, http2],
       tls => [
           {certfile, "cert.pem"},
           {keyfile, "key.pem"}
       ],
       routes => [{~"/", hello_handler, #{greeting => ~"hello"}}]
   }).

ALPN routes h2 clients to the HTTP/2 path and http/1.1 clients (or no-ALPN) to the HTTP/1.1 path on the same listener. Drop http2 from the list to disable HTTP/2. For HTTP/2 on plain TCP (h2c prior-knowledge per RFC 7540 §3.4), use protocols => [http2] without the tls opt.

For listeners that don't need routing, routes => Mod (or {Mod, State} to seed handler state) skips the router entirely and dispatches every request to Mod:handle/1:

roadrunner:start_listener(my_listener, #{
    port => 8080,
    routes => {hello_handler, #{greeting => ~"hello"}}
}).

Configuration

All listener options live in the roadrunner_listener:opts/0 type, with per-key defaults and tuning rationale. Beyond port, protocols, tls, and routes from the Quickstart, the type covers:

• DoS bounds — max_clients, max_content_length, request_timeout, keep_alive_timeout, min_bytes_per_second, max_keep_alive_requests
• Middleware — middlewares
• Body buffering — body_buffering
• Graceful drain — graceful_drain, slot_reconciliation
• Per-conn hibernation — hibernate_after
• HTTP/2 tunables (under the {http2, Opts} entry in protocols) — conn_window, stream_window, window_refill_threshold

Features

Handlers

• Buffered responses:{Status, Headers, Body} — roadrunner_resp:text/2, :html/2, :json/2, :redirect/2, plus empty-status shortcuts.
• Streaming:{stream, Status, Headers, Fun} — chunked transfer with a Send/2 callback; supports trailer headers per RFC 7230 §4.1.2.
• Loop / SSE:{loop, Status, Headers, State} + optional handle_info/3 callback for message-driven push.
• WebSocket:{websocket, Module, State} upgrade with roadrunner_ws_handler callback.
• Sendfile:{sendfile, Status, Headers, {Filename, Offset, Length}} — zero-copy file body via file:sendfile/5 (TCP) or chunked ssl:send fallback (TLS).

Routing

• roadrunner_router with literal / :param / *wildcard segments.
• Routes published to persistent_term for O(1) lookup; roadrunner_listener:reload_routes/2 swaps the table without restart.

Middleware

• Continuation-style (Req, Next) -> {Response, Req2} — listener-level + per-route, first-in-list = outermost.

Built-in handlers

• roadrunner_static for file serving with ETag, If-None-Match, Range, Last-Modified, If-Modified-Since, and configurable symlink policy (refuse_escapes default).

Hardening

• Strict RFC 9110 / 9112 parsing, with defenses grouped by subsystem:
  • Request smuggling / framing: CL+TE conflict, multiple-CL, chunk-size leading-whitespace rejection.
  • Header / control-frame injection: header CRLF / NUL rejection, SSE event-line CRLF rejection, trailer-header CRLF rejection, RFC 6455 §5.5 control-frame limits, RFC 6265 cookie OWS handling.
  • Sendfile path safety: path traversal + symlink escape defenses.
• TLS hardened defaults — TLS 1.2 / 1.3 only, AEAD-only cipher filter, client renegotiation off, post-quantum hybrid x25519mlkem768 first when the OpenSSL build supports it. Full settings list in the roadrunner_listener module docs.
• DoS bounds — max_clients, max_content_length, min_bytes_per_second, request_timeout, keep_alive_timeout, max_keep_alive_requests.

Observability

• telemetry events covering request, response, listener accept / close, slot reconciliation, ws upgrade and frames, and drain ack (opt-in via roadrunner:acknowledge_drain/1). Full event list with measurements / metadata in the roadrunner_telemetry module docs.
• Per-request request_id attached to logger:set_process_metadata/1 so any ?LOG_* from middleware/handlers is auto-correlated.
• roadrunner_listener:info/1 for pull-side active_clients / requests_served metrics.
• proc_lib:set_label/1 per-listener / per-acceptor / per-conn for legible observer process trees.

Lifecycle

• roadrunner_listener:drain/2 — graceful shutdown with timeout. Closes the listen socket, broadcasts {roadrunner_drain, Deadline} to in-flight conns via pg, polls until idle or deadline, then exit(Pid, shutdown) for stragglers.
• roadrunner_listener:status/1 — accepting | draining.
• Optional slot_reconciliation => #{interval => N} listener opt — a periodic reaper that compares client_counter against the conn pg group and releases slots orphaned by kill-style exits. Off by default; enable in production where you can't trust every exit path to run terminate/3 (kill signals, OOM kills, supervisor brutal-kill).

Documentation

• docs/comparison.md — full side-by-side benchmarks vs cowboy and elli (throughput, latency, architectural trade-offs, reproduction commands).
• docs/bench_results.md — full per-protocol matrix with p50 / p99 across every scenario.
• docs/bench_internals.md — loadgen worker model, latency aggregation, when the loader becomes the bottleneck.
• docs/wrk2_results.md — open-loop, Coordinated-Omission-corrected tail-latency tables (full per-scenario, all rate-points per server).
• docs/resource_results.md — memory + CPU shape per scenario.
• docs/conn_lifecycle_investigation.md — the connection-process model trade-offs and the one h2 case cowboy still wins.
• docs/roadmap.md — deferred items, with rough effort estimates for each.

Design philosophy

• RFC-correct, hostile-input-safe. Parsers are pure incremental binary matchers; only programmer errors raise, wire input always becomes {error, _}. Malformed bytes are bounded by length and rejected before reaching application code.
• Modern OTP idioms. Sigils for binary literals, body recursion (cons on the way out), binary keys for wire-derived data, -doc / -moduledoc markdown, dialyzer-clean specs. No binary_to_atom on parsed names.
• Continuation-style middleware.(Req, Next) -> {Response, Req2}, composable at listener and per-route level. Outermost first.
• Telemetry over custom callbacks.telemetry is the de facto standard (Phoenix, Ecto, gleam_otp); zero-overhead when no subscribers, integrates with prometheus / opentelemetry / datadog out of the box.
• No external deps unless stdlib genuinely can't. Only runtime dep is telemetry (tiny, no transitive deps); only dev-time dep is the erlfmt plugin.
