Modern push notifications for Elixir
Supports Apple APNS and Google FCM with HTTP/2, JWT authentication, and a clean unified API.
Table of Contents
- Features
- Quick Start
- Usage Guide
- Configuration
- Dynamic Instances (Runtime Config)
- Credential Storage
- Getting Your Credentials
- Telemetry
- Circuit Breaker
- Health Check
- Token Cleanup Callback
- Troubleshooting
- Contributing
- License
Features
- HTTP/2 connections via Finch (Mint-based) for optimal performance
- APNS (Apple Push Notification Service) with JWT authentication
- FCM (Firebase Cloud Messaging) with OAuth2 via Goth
- Web Push — FCM for Chrome/Firefox/Edge, APNS for Safari
- Batch sending — send to multiple tokens concurrently with configurable parallelism
- Token validation — validate token format before sending to catch errors early
- Rate limiting — optional client-side rate limiting to avoid provider throttling
- Automatic retry — exponential backoff for rate limits and server errors
- Telemetry — built-in instrumentation for metrics and monitoring
- Message builder — fluent API for constructing notifications
- Structured responses — consistent error handling across providers
- Zero JSON dependency — uses Elixir 1.18+ built-in JSON module
Requirements
- Elixir 1.18+ (for built-in JSON module)
- OTP 26+
Tested on Elixir 1.18/1.19 with OTP 26, 27, and 28.
Quick Start
1. Install
Add pushx to your dependencies in mix.exs:
def deps do
[
{:pushx, "~> 0.9"}
]
end2. Configure
Add credentials to config/runtime.exs:
config :pushx,
# APNS (iOS)
apns_key_id: System.fetch_env!("APNS_KEY_ID"),
apns_team_id: System.fetch_env!("APNS_TEAM_ID"),
apns_private_key: System.fetch_env!("APNS_PRIVATE_KEY"),
apns_mode: :prod,
# FCM (Android)
fcm_project_id: System.fetch_env!("FCM_PROJECT_ID"),
fcm_credentials: System.fetch_env!("FCM_CREDENTIALS") |> JSON.decode!()PushX starts its own HTTP/2 connection pools and OAuth processes automatically — no additional supervision tree setup needed.
Need help getting credentials? See Getting Your Credentials below.
3. Send a notification
# Send to iOS
PushX.push(:apns, device_token, "Hello!", topic: "com.example.app")
# Send to Android
PushX.push(:fcm, device_token, "Hello!")
# With title and body
PushX.push(:apns, token, %{title: "Welcome", body: "Thanks for signing up!"},
topic: "com.example.app")That's it. PushX handles HTTP/2 connections, JWT/OAuth authentication, and automatic retry.
Usage Guide
Message Builder
Build rich notifications with the fluent API:
message = PushX.message()
|> PushX.Message.title("Order Update")
|> PushX.Message.body("Your order #1234 has shipped")
|> PushX.Message.badge(1)
|> PushX.Message.sound("default")
|> PushX.Message.data(%{order_id: "1234", status: "shipped"})
PushX.push(:apns, token, message, topic: "com.example.app")| Function | Description |
|---|---|
title(msg, string) | Set notification title |
body(msg, string) | Set notification body |
badge(msg, integer) | Set app badge count (iOS) |
sound(msg, string) | Set notification sound |
data(msg, map) | Set custom data payload |
put_data(msg, key, value) | Add single data key-value |
category(msg, string) | Set notification category (iOS) |
thread_id(msg, string) | Set thread ID for grouping (iOS) |
image(msg, url) | Set image URL (FCM) |
priority(msg, :high | :normal) | Set delivery priority |
ttl(msg, seconds) | Set time-to-live |
collapse_key(msg, string) | Set collapse key (FCM) |
You can also pass a plain string, a %{title: ..., body: ...} map, or a raw APNS/FCM payload map directly to push/4.
Response Handling
Every push returns {:ok, Response} or {:error, Response}:
case PushX.push(:apns, token, message, topic: "com.example.app") do
{:ok, %PushX.Response{status: :sent, id: apns_id}} ->
Logger.info("Notification sent with ID: #{apns_id}")
{:error, %PushX.Response{} = response} ->
if PushX.Response.should_remove_token?(response) do
# Token is invalid, expired, or unregistered — delete it
MyApp.Tokens.delete(token)
else
Logger.error("Push failed: #{response.status} - #{response.reason}")
end
endResponse struct:
%PushX.Response{
provider: :apns | :fcm,
status: :sent | :invalid_token | :expired_token | ...,
id: "message-id" | nil,
reason: "error reason" | nil,
raw: raw_response_body,
retry_after: seconds | nil
}| Status | Description | Action |
|---|---|---|
:sent | Successfully delivered | None |
:invalid_token | Token is malformed or invalid | Remove token |
:expired_token | Token has expired | Remove token |
:unregistered | Device unregistered | Remove token |
:payload_too_large | Payload exceeds limit (APNS: 4KB, FCM: 4000 bytes) | Reduce payload size |
:rate_limited | Too many requests | Automatic retry with backoff |
:server_error | Provider server error | Automatic retry with backoff |
:connection_error | Network failure | Automatic retry with backoff |
:invalid_request |
Missing required option (e.g., no :topic for APNS) | Fix request parameters |
:auth_error | JWT/credential failure (e.g., invalid private key) | Check credentials |
:unknown_error | Unrecognized error |
Check reason field |
Helper functions:
PushX.Response.success?(response) # true if status == :sent
PushX.Response.should_remove_token?(response) # true for invalid/expired/unregistered
PushX.Response.retryable?(response) # true for connection_error/rate_limited/server_errorBatch Sending
Send to multiple devices concurrently:
results = PushX.push_batch(:apns, tokens, message, topic: "com.example.app")
# Process results
Enum.each(results, fn
{token, {:ok, response}} -> Logger.info("Sent to #{token}")
{token, {:error, response}} ->
if PushX.Response.should_remove_token?(response) do
MyApp.Tokens.delete(token)
end
end)| Option | Type | Default | Description |
|---|---|---|---|
:concurrency | integer() | 50 | Max concurrent requests |
:timeout | integer() | 30_000 | Timeout per request (ms) |
:validate_tokens | boolean() | false | Filter invalid tokens before sending |
For aggregate counts, use the bang variant:
%{success: 95, failure: 5, total: 100} =
PushX.push_batch!(:fcm, tokens, "Hello!")Silent/Background Notification
payload = PushX.APNS.silent_notification(%{action: "sync", resource: "messages"})
PushX.APNS.send(token, payload,
topic: "com.example.app",
push_type: "background",
priority: 5
)Data-Only Message (FCM)
Send data without a visible notification. All values are automatically converted to strings (FCM requirement):
# Via unified API (supports named instances)
PushX.push_data(:fcm, token, %{action: "sync", id: 123})
PushX.push_data(:my_fcm, token, %{action: "sync", id: 123})
# Via provider module directly
PushX.FCM.send_data(token, %{action: "sync", id: 123})Notification with Custom Data (FCM)
Send a visible notification with a custom data payload attached:
# Structured payload — notification + data
PushX.push(:fcm, token, %{
"notification" => %{"title" => "Alert", "body" => "Something happened"},
"data" => %{"event_id" => "1", "action" => "open_event"}
})
# Works with named instances too
PushX.push(:my_fcm, token, %{
"notification" => %{"title" => "Alert", "body" => "Something happened"},
"data" => %{"event_id" => "1"}
})Web Push
FCM Web Push (Chrome, Firefox, Edge)
FCM uses the same API for web and mobile. Web tokens come from Firebase Messaging SDK.
# Same API as mobile
PushX.push(:fcm, web_token, %{title: "Hello", body: "From web!"})
# With click action
PushX.FCM.send_web(web_token, "New Message", "Check it out",
"https://example.com/messages")
# With icon and badge
PushX.FCM.send_web(web_token, "Alert", "Important update",
"https://example.com",
icon: "https://example.com/icon.png",
badge: "https://example.com/badge.png"
)
# Build payload manually for more control
payload = PushX.FCM.web_notification("Title", "Body", "https://example.com",
icon: "https://example.com/icon.png",
require_interaction: true
)
PushX.FCM.send(web_token, payload)Safari Web Push (macOS)
Safari uses APNS with a web. topic prefix. Tokens are 64 hex characters (same as iOS).
# Topic format: web.{website-push-id}
payload = PushX.APNS.web_notification("New Article", "Check it out",
"https://example.com/article/123")
PushX.APNS.send(safari_token, payload, topic: "web.com.example.website")
# With custom action button and data
payload = PushX.APNS.web_notification_with_data("Sale!", "50% off",
"https://shop.com",
%{"promo_id" => "summer50"},
action: "Shop Now"
)Direct Provider Access
The unified PushX.push/4 normalizes payloads across providers. When you need provider-specific features, use the modules directly:
# APNS — full control over headers and payload
PushX.APNS.send(token, payload, topic: "com.app", push_type: "voip")
PushX.APNS.send_once(token, payload, opts) # no automatic retry
PushX.APNS.send_batch(tokens, payload, opts)
PushX.APNS.notification("Title", "Body", badge)
PushX.APNS.notification_with_data("Title", "Body", %{key: "value"})
PushX.APNS.silent_notification(%{action: "sync"})
PushX.APNS.web_notification("Title", "Body", "https://url")
PushX.APNS.web_notification_with_data("Title", "Body", "https://url", %{key: "val"})
# FCM — full control over android/webpush/data options
PushX.FCM.send(token, payload, data: %{key: "value"})
PushX.FCM.send_once(token, payload, opts) # no automatic retry
PushX.FCM.send_batch(tokens, payload, opts)
PushX.FCM.send_data(token, %{key: "value"}) # data-only, no visible notification
PushX.FCM.send_web(token, "Title", "Body", "https://link", opts)
PushX.FCM.notification("Title", "Body", image: "https://img")
PushX.FCM.web_notification("Title", "Body", "https://link", opts)
PushX.FCM.web_notification_with_data("Title", "Body", "https://link", %{key: "val"})Token Validation
Validate tokens before sending to catch format errors early:
PushX.valid_token?(:apns, token) # true/false
PushX.validate_token(:apns, token) # :ok | {:error, :empty | :invalid_length | :invalid_format}
# In batch — filter out bad tokens automatically
PushX.push_batch(:apns, tokens, message, topic: "...", validate_tokens: true)APNS tokens: exactly 64 hexadecimal characters (32 bytes) FCM tokens: 20-500 characters, alphanumeric with hyphens/underscores/colons
Configuration
All configuration goes under config :pushx. Here's a complete example with all options:
config :pushx,
# === Credentials ===
apns_key_id: "ABC123DEFG",
apns_team_id: "TEAM123456",
apns_private_key: {:file, "priv/keys/AuthKey.p8"},
apns_mode: :prod,
fcm_project_id: "my-project-id",
fcm_credentials: {:file, "priv/keys/firebase.json"},
# === HTTP/2 Pool (tune for your traffic level) ===
finch_pool_size: 2, # connections per pool (default: 25)
finch_pool_count: 1, # number of pools (default: 2)
# === Timeouts ===
receive_timeout: 15_000, # wait for response data (default: 15s)
pool_timeout: 5_000, # wait for pool connection (default: 5s)
connect_timeout: 10_000, # TCP connect timeout (default: 10s)
# === Retry ===
retry_enabled: true, # default: true
retry_max_attempts: 3, # default: 3
retry_base_delay_ms: 10_000, # default: 10s (Google's recommended minimum)
retry_max_delay_ms: 60_000, # default: 60s
# === Rate Limiting (optional) ===
rate_limit_enabled: false, # default: false
rate_limit_apns: 5000, # requests per window
rate_limit_fcm: 5000, # requests per window
rate_limit_window_ms: 1000 # 1 second windowCredentials
APNS
| Option | Type | Description |
|---|---|---|
:apns_key_id | String.t() | 10-character Key ID from Apple |
:apns_team_id | String.t() | 10-character Team ID from Apple |
:apns_private_key | String.t() | {:file, path} | {:system, env_var} | PEM string, file path, or env var name |
:apns_mode | :prod | :sandbox |
APNS environment (default: :prod) |
FCM
| Option | Type | Description |
|---|---|---|
:fcm_project_id | String.t() | Firebase project ID |
:fcm_credentials | map() | {:file, path} | {:json, string} | {:system, env_var} | Service account as map, file, JSON string, or env var |
Pool Sizing
Each HTTP/2 connection supports ~100 concurrent streams. Pool capacity = pool_size x pool_count x 100.
| Traffic Level | pool_size | pool_count | Concurrent Capacity |
|---|---|---|---|
| Low (<100/min) | 2 | 1 | ~200 |
| Medium (<1000/min) | 10 | 1 | ~1,000 |
| High (>1000/min) | 25 | 2 | ~5,000 |
| Very high | 50 | 4 | ~20,000 |
Important: For low-traffic apps, reduce pool size from the defaults. Large pools create many idle HTTP/2 connections that can go stale on cloud infrastructure (Fly.io, AWS, GCP), leading to
too_many_concurrent_requestserrors. Start small and increase only if needed.
Retry Behavior
PushX automatically retries transient failures with exponential backoff:
- Connection errors — reconnects the HTTP pool, then retries with 1s base delay (1s, 2s, 4s)
- Server errors (5xx) — 10s base delay (10s, 20s, 40s) per Google's recommendation
- Rate limited (429) — uses
retry-afterheader, or 60s default - Permanent failures — never retried (invalid token, payload too large, etc.)
To skip retry for a specific call, use send_once:
PushX.APNS.send_once(token, payload, topic: "com.example.app")
PushX.FCM.send_once(token, payload)Timeouts
| Option | Default | Description |
|---|---|---|
:receive_timeout | 15s | How long to wait for response data from APNS/FCM |
:pool_timeout | 5s | How long to wait for a connection from the pool |
:connect_timeout | 10s | TCP connection establishment timeout |
Tip: Increase timeouts if connecting from distant regions (e.g., EU to Apple's US servers).
You can also override timeouts per-request:
PushX.APNS.send(token, payload,
topic: "com.example.app",
receive_timeout: 30_000,
pool_timeout: 10_000
)Rate Limiting
Optional client-side rate limiting prevents exceeding provider limits. Disabled by default.
# Check manually before sending
case PushX.check_rate_limit(:apns) do
:ok -> # proceed
{:error, :rate_limited} -> # back off
end
When enabled, rate limits are checked automatically before each send call.
Dynamic Instances (Runtime Config)
For applications that manage push credentials from a database or admin panel, PushX supports starting, stopping, and reconfiguring provider instances at runtime — no application restart needed.
Each instance gets its own HTTP/2 connection pool, JWT cache (APNS), and OAuth process (FCM). Multiple instances can run concurrently (e.g., APNS sandbox + APNS prod + FCM).
Starting Instances
# APNS sandbox (for development/testing)
PushX.Instance.start(:apns_sandbox, :apns,
key_id: "ABC123",
team_id: "TEAM456",
private_key: apns_key_pem,
mode: :sandbox
)
# APNS production
PushX.Instance.start(:apns_prod, :apns,
key_id: "ABC123",
team_id: "TEAM456",
private_key: apns_key_pem,
mode: :prod
)
# FCM
PushX.Instance.start(:my_fcm, :fcm,
project_id: "my-firebase-project",
credentials: service_account_map
)
The names :apns and :fcm are reserved for the static config path and cannot be used as instance names.
Sending via Instances
Pass the instance name instead of :apns or :fcm:
PushX.push(:apns_prod, device_token, "Hello!", topic: "com.example.app")
PushX.push(:my_fcm, device_token, %{title: "Alert", body: "Something happened"})
# Data-only (silent) message via instance
PushX.push_data(:my_fcm, device_token, %{action: "sync", id: 123})Batch sending works the same way:
PushX.push_batch(:apns_prod, tokens, message, topic: "com.example.app")Enable / Disable
Disable an instance to reject new pushes while keeping the connection pool warm:
PushX.Instance.disable(:apns_sandbox)
# => PushX.push(:apns_sandbox, ...) returns {:error, %Response{status: :provider_disabled}}
PushX.Instance.enable(:apns_sandbox)
# => pushes work againReconfigure
Update config without restarting the application. The old pool is stopped and a new one starts with the merged config:
# Switch environment
PushX.Instance.reconfigure(:apns_sandbox, mode: :prod)
# Rotate credentials
PushX.Instance.reconfigure(:apns_prod,
key_id: "NEW_KEY_ID",
private_key: new_pem_string
)List and Status
PushX.Instance.list()
#=> [
#=> %{name: :apns_prod, provider: :apns, enabled: true},
#=> %{name: :apns_sandbox, provider: :apns, enabled: false},
#=> %{name: :my_fcm, provider: :fcm, enabled: true}
#=> ]
PushX.Instance.status(:apns_prod)
#=> {:ok, %{provider: :apns, enabled: true}}Stop
PushX.Instance.stop(:apns_sandbox)Cleans up the Finch pool, JWT cache, Goth process (FCM), and ETS entry.
Example: Database-Backed Admin Panel
defmodule MyApp.PushAdmin do
@doc "Boot all saved instances on application start."
def boot do
MyApp.Repo.all(MyApp.PushConfig)
|> Enum.each(fn config ->
PushX.Instance.start(
String.to_atom(config.name),
String.to_atom(config.provider),
build_opts(config)
)
end)
end
@doc "Called from admin panel when config is updated."
def update(config) do
name = String.to_atom(config.name)
PushX.Instance.reconfigure(name, build_opts(config))
end
@doc "Called from admin panel toggle."
def toggle(name, enabled?) do
if enabled?,
do: PushX.Instance.enable(name),
else: PushX.Instance.disable(name)
end
defp build_opts(%{provider: "apns"} = c) do
[
key_id: c.key_id,
team_id: c.team_id,
private_key: c.private_key,
mode: String.to_atom(c.mode)
]
end
defp build_opts(%{provider: "fcm"} = c) do
[
project_id: c.project_id,
credentials: JSON.decode!(c.credentials_json)
]
end
end
Call MyApp.PushAdmin.boot() from your Application.start/2 after PushX starts.
Instance Config Options
| Option | Type | Default | Description |
|---|---|---|---|
:key_id | String.t() | required (APNS) | Apple Key ID |
:team_id | String.t() | required (APNS) | Apple Team ID |
:private_key | String.t() | {:file, path} | {:system, env} | required (APNS) | PEM private key |
:mode | :prod | :sandbox | :prod | APNS environment |
:project_id | String.t() | required (FCM) | Firebase project ID |
:credentials | map() | String.t() | required (FCM) | Service account (map or JSON string) |
:pool_size | integer() | 2 | Finch connections per pool |
:pool_count | integer() | 1 | Number of Finch pools |
:receive_timeout | integer() | 15_000 | Response timeout (ms) |
:pool_timeout | integer() | 5_000 | Pool checkout timeout (ms) |
:connect_timeout | integer() | 10_000 | TCP connect timeout (ms) |
Credential Storage
File System (Development)
# config/dev.exs
config :pushx,
apns_private_key: {:file, "priv/keys/AuthKey.p8"},
fcm_credentials: {:file, "priv/keys/firebase-service-account.json"}
Add /priv/keys/ to .gitignore.
Environment Variables (Production)
# config/runtime.exs
config :pushx,
apns_key_id: System.get_env("APNS_KEY_ID"),
apns_team_id: System.get_env("APNS_TEAM_ID"),
apns_private_key: System.get_env("APNS_PRIVATE_KEY"),
apns_mode: if(System.get_env("APNS_SANDBOX") == "true", do: :sandbox, else: :prod),
fcm_project_id: System.get_env("FCM_PROJECT_ID"),
fcm_credentials: System.get_env("FCM_CREDENTIALS") |> JSON.decode!()Tip: For multiline keys (APNS .p8), set the env var directly from the file:
export APNS_PRIVATE_KEY="$(cat AuthKey.p8)"
Fly.io Secrets
fly secrets set APNS_KEY_ID="ABC123DEFG"
fly secrets set APNS_TEAM_ID="TEAM123456"
fly secrets set APNS_PRIVATE_KEY="$(cat AuthKey.p8)"
fly secrets set FCM_PROJECT_ID="my-project-id"
fly secrets set FCM_CREDENTIALS="$(cat firebase-service-account.json)"
Then use System.fetch_env!/1 in config/runtime.exs:
if config_env() == :prod do
config :pushx,
apns_key_id: System.fetch_env!("APNS_KEY_ID"),
apns_team_id: System.fetch_env!("APNS_TEAM_ID"),
apns_private_key: System.fetch_env!("APNS_PRIVATE_KEY"),
apns_mode: :prod,
fcm_project_id: System.fetch_env!("FCM_PROJECT_ID"),
fcm_credentials: System.fetch_env!("FCM_CREDENTIALS") |> JSON.decode!()
endAWS Secrets Manager / Vault
if config_env() == :prod do
{:ok, %{"SecretString" => apns_key}} =
ExAws.SecretsManager.get_secret_value("pushx/apns-key")
|> ExAws.request()
config :pushx,
apns_private_key: apns_key
endGetting Your Credentials
Apple APNS Setup
You need: Key ID, Team ID, and a Private Key (.p8 file).
Step 1: Get Your Team ID
- Go to Apple Developer Account
- Your Team ID is shown in the top-right corner (10 characters)
Step 2: Create an APNS Key
- Go to Certificates, Identifiers & Profiles
- Click Keys > + (Create a new key)
- Enter a name (e.g., "Push Notifications Key")
- Check Apple Push Notifications service (APNs)
- Click Continue > Register
- Download the .p8 file (you can only download it once!)
- Note the Key ID shown (10 characters)
Google FCM Setup
You need: Project ID and a Service Account JSON file.
Step 1: Create/Open Firebase Project
- Go to Firebase Console
- Create a new project or select an existing one
- Note your Project ID in Project Settings
Step 2: Enable Cloud Messaging API
- Go to Google Cloud Console
- Select your Firebase project
- Go to APIs & Services > Library
- Search for "Firebase Cloud Messaging API" and Enable it
Step 3: Create Service Account Key
- In Firebase Console, go to Project Settings (gear icon)
- Click Service accounts tab
- Click Generate new private key
- Save the JSON file securely
Credential Rotation
APNS .p8 keys and FCM service accounts don't expire. You only need to rotate them if you revoke a key or want to follow a rotation policy.
With restart (simplest)
- Generate new credentials in Apple/Google console
-
Update your secrets (Fly:
fly secrets set, AWS: update in Secrets Manager) - Redeploy your app
- Revoke old credentials after all instances are updated
Without restart (static config)
The static config path reads credentials from Application env on each JWT generation, so you can hot-swap them at runtime:
# 1. Update application env with new credentials
Application.put_env(:pushx, :apns_key_id, "NEW_KEY_ID")
Application.put_env(:pushx, :apns_private_key, new_pem_string)
# 2. Clear the cached JWT (otherwise the old token is used for up to 50 min)
:persistent_term.erase(:pushx_apns_jwt_cache)
# 3. Reconnect to discard connections authenticated with the old token
PushX.reconnect()For FCM, Goth manages OAuth2 tokens automatically. To rotate service account credentials without restart, use the dynamic instance API below.
Without restart (dynamic instances)
If you use PushX.Instance, call reconfigure/2 — it stops the old pool and starts a fresh one with the new credentials:
PushX.Instance.reconfigure(:apns_prod,
key_id: "NEW_KEY_ID",
private_key: new_pem_string
)In-flight requests on the old pool get connection errors, which the retry logic handles automatically.
Telemetry
PushX emits telemetry events for monitoring and metrics:
| Event | When | Measurements | Metadata |
|---|---|---|---|
[:pushx, :push, :start] | Request starts | system_time | provider, token |
[:pushx, :push, :stop] | Request succeeds | duration | provider, token, status, id |
[:pushx, :push, :error] | Request fails | duration | provider, token, status, reason |
[:pushx, :push, :exception] | Exception raised | duration | provider, token, kind, reason |
[:pushx, :retry, :attempt] | Retry attempted | delay_ms, attempt | provider, status |
Tokens are automatically truncated in telemetry metadata for privacy (first 8 + last 4 characters).
Example: Attach a Logger
# In your Application.start/2
:telemetry.attach_many(
"pushx-logger",
[
[:pushx, :push, :stop],
[:pushx, :push, :error]
],
fn
[:pushx, :push, :stop], %{duration: d}, %{provider: p}, _ ->
ms = System.convert_time_unit(d, :native, :millisecond)
Logger.info("PushX #{p} sent in #{ms}ms")
[:pushx, :push, :error], _, %{provider: p, status: s, reason: r}, _ ->
Logger.warning("PushX #{p} failed: #{s} - #{r}")
end,
nil
)Example: With Telemetry.Metrics
defmodule MyApp.Telemetry do
import Telemetry.Metrics
def metrics do
[
counter("pushx.push.stop.count", tags: [:provider]),
counter("pushx.push.error.count", tags: [:provider, :status]),
distribution("pushx.push.stop.duration",
unit: {:native, :millisecond},
tags: [:provider]
)
]
end
endCircuit Breaker
PushX includes an optional circuit breaker that temporarily blocks requests to a provider after consecutive failures. This prevents wasting resources on dead connections.
config :pushx,
circuit_breaker_enabled: true,
circuit_breaker_threshold: 5, # consecutive failures to trip
circuit_breaker_cooldown_ms: 30_000 # ms before retryingStates:
- Closed — Normal operation, all requests flow through
- Open — Provider is failing, requests are immediately rejected with
{:error, %Response{status: :circuit_open}} - Half-open — After cooldown, one probe request is allowed. Success closes the circuit; failure re-opens it
Only :connection_error and :server_error responses count as failures. Invalid tokens and rate limits do not trip the circuit.
# Check circuit breaker state
PushX.CircuitBreaker.state(:apns)
#=> :closed
# Manual reset
PushX.CircuitBreaker.reset(:apns)Health Check
Check provider configuration and circuit breaker status:
PushX.health_check()
#=> %{
#=> apns: %{configured: true, circuit: :closed},
#=> fcm: %{configured: true, circuit: :closed}
#=> }Token Cleanup Callback
Automatically clean up invalid tokens from your database when a push fails with :invalid_token, :expired_token, or :unregistered:
config :pushx,
on_invalid_token: {MyApp.Push, :handle_invalid_token, []}
The callback receives (provider, device_token, ...extra_args) and runs asynchronously:
defmodule MyApp.Push do
def handle_invalid_token(provider, device_token) do
MyApp.Tokens.delete_by_token(device_token)
Logger.info("Removed invalid #{provider} token")
end
endTroubleshooting
too_many_concurrent_requests Error
This Mint HTTP/2 error means all streams on a connection are in use. It has two common causes with opposite fixes:
[error] [PushX.APNS] Connection error: %Mint.HTTPError{reason: :too_many_concurrent_requests}Cause 1: Stale connections (low-traffic apps)
On cloud infrastructure (Fly.io, AWS, GCP), idle HTTP/2 connections can be silently dropped by load balancers or firewalls. The client doesn't know the connection is dead, so new requests on it hang or fail. PushX enables TCP keepalive to detect dead connections at the OS level, and automatically reconnects on connection errors during retry.
Fix: Reduce pool size to minimize idle connections:
config :pushx,
finch_pool_size: 2,
finch_pool_count: 1You can also force a reconnect manually:
PushX.reconnect()Cause 2: Actual overload (high-traffic apps)
If you're sending thousands of notifications per minute, the pool may genuinely run out of HTTP/2 streams.
Fix: Increase pool capacity and use rate limiting:
config :pushx,
finch_pool_size: 50,
finch_pool_count: 4,
rate_limit_enabled: true,
rate_limit_apns: 2000,
rate_limit_fcm: 2000request_timeout Error
[error] [PushX.APNS] Connection error: %Finch.Error{reason: :request_timeout}Increase timeouts if connecting from distant regions (e.g., EU to US):
config :pushx, receive_timeout: 30_000, connect_timeout: 20_000PushX automatically retries connection errors with exponential backoff (1s, 2s, 4s)
If this follows a
too_many_concurrent_requestserror, see the stale connections fix above
Debugging Tips
Enable telemetry logging to monitor push performance:
:telemetry.attach("pushx-debug", [:pushx, :push, :error], fn _, _, meta, _ ->
Logger.warning("Push failed: #{meta.provider} - #{meta.status} - #{meta.reason}")
end, nil)Contributing
Contributions are welcome! Please feel free to submit a Pull Request.
- Fork the repository
-
Create your feature branch (
git checkout -b feature/amazing-feature) -
Commit your changes (
git commit -m 'Add some amazing feature') -
Push to the branch (
git push origin feature/amazing-feature) - Open a Pull Request
License
MIT License. See LICENSE for details.
Built with care by Cigno Systems AB
