Merkel
Implements a balanced, merkle binary hash tree. WikipediaBitcoin
Merkle trees are a beautiful data structure for summarizing and verifying data integrity. They are named in honor of distinguished computer scientist Ralph Merkle. This library is named with a slight twist (le to el :arrows_clockwise:) to salute Angela Merkel's push for algorithmic transparency.
“I am of the opinion that algorithms must be made more transparent so that one can inform oneself as an interested citizen about questions like, ‘What influences my behaviour on the internet and that of others?’”
“These algorithms — when they are not transparent — can lead to a distortion of our perception. They narrow our breadth of information.” Source
A Source of Data Integrity -
The reason why this works is that hashes propagate upward: if a malicious user attempts to swap in a fake transaction into the bottom of a Merkle tree, this change will cause a change in the node above, and then a change in the node above that, finally changing the root of the tree and therefore the hash of the block, causing the protocol to register it as a completely different block (almost certainly with an invalid proof of work)"
Noteworthy
- Uses AVL rotations :arrows_clockwise: to keep the tree balanced (relying on inner search keys for order property)
- Creation from list creates a balanced tree without any initial rotations or rehashings (RECOMMENDED)
- Supports key value storage, retrieval, and deletion
- Supports these hash algorithms: md5, ripemd160, sha, sha224, sha256, sha384, sha512 - See crypto
- Supports specifying a custom hash function with arity 1, which accepts a binary argument and returns a binary
- Provides proof of existence in verifiable format
- Keys are binary, and values are any type (use your discretion if you want the tree to be more compact)
- Supports simple serialization and deserialization
- Uses property testing
Usage
Note: Since keys are binaries we will use mostly String keys for visual clarity
Helpful background
iex> l = [{"zebra", 23}, {"daisy", "932"}, {"giraffe", 29}, {"anteater", "12"}, {"walrus", 49}]
iex> Enum.map(l, fn {k, _v} -> {k, Merkel.Crypto.hash(k)} end)
[
{"zebra", "676cb75018edccf10fce6f376f2124e02c3293fa3fe8f953c75386198c714514"},
{"daisy", "42029ef215256f8fa9fedb53542ee6553eef76027b116f8fac5346211b1e473c"},
{"giraffe", "6bb7e067447139b18f6094d2d15bcc264affde89a8b9f5227fe5b38abd8b19d7"},
{"anteater", "b0ce2ef96d43c0e0f83d57785f9a87b647065ca75360ca5e9de520e7f690c3f9"},
{"walrus", "9671014645ce9d6f8bae746fded25064937658d712004bd01d8f4c093c387bf3"}
]- Create new MHT
iex> m1 = Merkel.new(l)
#Merkel.Tree<{5,
{"f92f0f98d165457a4122bbe165aefa14928f45943f9b11880b51d720a1ad37c1", "<=gi..>",
3,
{"bbe4..", "<=da..>", 2,
{"5ad2..", "<=an..>", 1, {"b0ce..", "anteater", 0}, {"4202..", "daisy", 0}},
{"6bb7..", "giraffe", 0}},
{"9b02..", "<=wa..>", 1, {"9671..", "walrus", 0}, {"676c..", "zebra", 0}}}}>iex> Merkel.keys(m1)
["anteater", "daisy", "giraffe", "walrus", "zebra"]iex> Merkel.to_list(m1)
[
{"anteater", "12"},
{"daisy", "932"},
{"giraffe", 29},
{"walrus", 49},
{"zebra", 23}
]# Notes:
# double letter represents inner node search keys abbreviations,
# whose left values are <= to the search key, and right values are >
# gi is the root node with search key giraffe at height 3, with merkle hash: f92f..
# ant is abbreviated for anteater for space
# leaves are at height 0
3 gi 3
/ \
2 da wa 1
/ \ / \
1 an giraffe walrus zebra 0
/ \
0 ant daisy- Create new MHT with binary keys that aren't printable strings
iex> l = [{<<231,23, 11>>, 23}, {<<108,1>>, "932"}, {<<21, 11>>, 29},
{"anteater" <> <<0>>, "12"}, {"walrus" <> <<0>>, 49}]
iex> Merkel.new(l)
#Merkel.Tree<{5,
{"dfa6c9257e371e7717047eec853604174816f92238cf04057a720aabff405897",
<<108, 1>>, 3,
{"7eb5..", "<=an..>", 2,
{"eca4..", <<21, 11>>, 1, {"60c2..", <<21, 11>>, 0},
{"7931..", <<97, 110, 116, 101, 97, 116, 101, 114, 0>>, 0}},
{"a233..", <<108, 1>>, 0}},
{"9ccb..", "<=wa..>", 1, {"5122..", <<119, 97, 108, 114, 117, 115, 0>>, 0},
{"e93a..", <<231, 23, 11>>, 0}}}}> 3 <<108,1>> 3
/ \
2 an wa 1
/ \ / \
1 <<21,11> <<108,1>> <<119,97..> <<231,2..> 0
/ \
0 <<21,11> <<97, 110..>- Lookup key value
iex> Merkel.lookup(m1, "walrus")
{:ok, 49}- Insert key value pairs (and notice rotations)
iex> m2 = Merkel.insert(m1, {"aardvark", 999})
#Merkel.Tree<{6,
{"17b632f2e3ee68ef4bb880825c7d6bf3c674c9f0fb4d8f81a5654590e107f936", "<=gi..>",
3,
{"b1f2..", "<=an..>", 2,
{"2fc5..", "<=aa..>", 1, {"cf9c..", "aardvark", 0},
{"b0ce..", "anteater", 0}},
{"92af..", "<=da..>", 1, {"4202..", "daisy", 0}, {"6bb7..", "giraffe", 0}}},
{"9b02..", "<=wa..>", 1, {"9671..", "walrus", 0}, {"676c..", "zebra", 0}}}}> gi
/ \
an wa
/ \ / \
aa da walrus zebra
/ \ / \
aardvark ant daisy giraffeiex> m3 = Merkel.insert(m2, {"elephant", "He's big"})
#Merkel.Tree<{7,
{"af4b1fc2c7a9189aad3b4b60ee8d5235c7df262264e77ce62622f32725eb0424", "<=da..>",
3,
{"1779..", "<=an..>", 2,
{"2fc5..", "<=aa..>", 1, {"cf9c..", "aardvark", 0},
{"b0ce..", "anteater", 0}}, {"4202..", "daisy", 0}},
{"add5..", "<=gi..>", 2,
{"3b00..", "<=el..>", 1, {"cd08..", "elephant", 0}, {"6bb7..", "giraffe", 0}},
{"9b02..", "<=wa..>", 1, {"9671..", "walrus", 0}, {"676c..", "zebra", 0}}}}}> da
/ \
an gi
/ \ / \
aa daisy el wa
/ \ / \ / \
aardvark ant elephant giraffe walr zebra- Delete key
# "daisy" is not an animal type, delete!
iex> {:ok, m4} = Merkel.delete(m3, "daisy")
{:ok,
#Merkel.Tree<{6,
{"9820eab565a08738588256687c806fa2df46b094f2eb8565568d573447361c0a",
"<=an..>", 3,
{"2fc5..", "<=aa..>", 1, {"cf9c..", "aardvark", 0},
{"b0ce..", "anteater", 0}},
{"add5..", "<=gi..>", 2,
{"3b00..", "<=el..>", 1, {"cd08..", "elephant", 0},
{"6bb7..", "giraffe", 0}},
{"9b02..", "<=wa..>", 1, {"9671..", "walrus", 0}, {"676c..", "zebra", 0}}}}}>} an
/ \
aa gi
/ \ / \
aardvark anteater el wa
/ \ / \
elephant giraffe walr zebra- Insert key value
iex> m5 = Merkel.insert(m4, {"penguin", :waddle})
#Merkel.Tree<{7,
{"e79f6fa607ad5d0a8e93a8ba759b266d52a71471222f11fe1ab07ee89ef9f4a4", "<=gi..>",
3,
{"3c2f..", "<=an..>", 2,
{"2fc5..", "<=aa..>", 1, {"cf9c..", "aardvark", 0},
{"b0ce..", "anteater", 0}},
{"3b00..", "<=el..>", 1, {"cd08..", "elephant", 0}, {"6bb7..", "giraffe", 0}}},
{"0d77..", "<=wa..>", 2,
{"b881..", "<=pe..>", 1, {"0a43..", "penguin", 0}, {"9671..", "walrus", 0}},
{"676c..", "zebra", 0}}}}> gi
/ \
an wa
/ \ / \
aa el pe zebra
/ \ / \ / \
aardvark ant elep giraffe penguin walrus- Update value for key
- Get all keys
iex> m6 = Merkel.insert(m5, {"walrus", {"eats too many fish"}})
..(same as above)..
iex> Merkel.lookup(m6, "walrus")
{:ok, {"eats too many fish"}}
iex> Merkel.keys(m6)
["aardvark", "anteater", "elephant", "giraffe", "penguin", "walrus", "zebra"]- Create audit proof
- Note: the audit path is in a special tuple form reflective of audit trail order
iex> proof = Merkel.audit(m6, "elephant")
%Merkel.Audit{
key: "elephant",
path: {{"2fc521eca930a09a28bad66d9a1380f7cfe895c77f17c7f8996a840471ba857d",
{{}, "6bb7e067447139b18f6094d2d15bcc264affde89a8b9f5227fe5b38abd8b19d7"}},
"0d77466195f02be2c49cf4d1f00a6b35d70b522ca7adbf9c22f769feca5cf29b"}==== denotes key
---- denotes audit hashes
gi
/ \
an wa (0d77..)
-----
/ \ / \
(2fc5..) aa el pe zebra
----
/ \ / \ / \
aardvark ant elep giraffe penguin walrus
==== -------
(6bb7..)- Verify audit proof
iex> Merkel.verify(proof, Merkel.tree_hash(m6))
true- Pretty print
iex> Merkel.print(m6)
0 zebra 676c..
/
2 <=wa..> 0d77..
\
0 walrus 9671..
/
1 <=pe..> b881..
\
0 penguin 0a43..
/
3 <=gi..> e79f6fa607ad5d0a8e93a8ba759b266d52a71471222f11fe1ab07ee89ef9f4a4 (Merkle Root)
\
0 giraffe 6bb7..
/
1 <=el..> 3b00..
\
0 elephant cd08..
/
2 <=an..> 3c2f..
\
0 anteater b0ce..
/
1 <=aa..> 2fc5..
\
0 aardvark cf9c..
:ok- Dump, Store, New
iex> etf = Merkel.dump(m6)
<<131, 116, 0, 0, 0, 3, 100, 0, 10, 95, 95, 115, 116, 114, 117, 99, 116, 95, 95,
100, 0, 28, 69, 108, 105, 120, 105, 114, 46, 77, 101, 114, 107, 101, 108, 46,
66, 105, 110, 97, 114, 121, 72, 97, 115, 104, 84, 114, 101, 101, ...>>
iex> Merkel.store(m6, "./merkel.tmp")
iex> Merkel.new(etf: etf)
#Merkel.Tree<{7,
{"e79f6fa607ad5d0a8e93a8ba759b266d52a71471222f11fe1ab07ee89ef9f4a4", "<=gi..>",
3,
{"3c2f..", "<=an..>", 2,
{"2fc5..", "<=aa..>", 1, {"cf9c..", "aardvark", 0},
{"b0ce..", "anteater", 0}},
{"3b00..", "<=el..>", 1, {"cd08..", "elephant", 0}, {"6bb7..", "giraffe", 0}}},
{"0d77..", "<=wa..>", 2,
{"b881..", "<=pe..>", 1, {"0a43..", "penguin", 0}, {"9671..", "walrus", 0}},
{"676c..", "zebra", 0}}}}>
iex> Merkel.new(path: "./merkel.tmp")
..(same as above)..Configure
- Configure the hash algorithm to override the default :sha256 (if necessary)
# Override in config.exs
# Options are: :md5, :ripemd160, :sha, :sha224, :sha256, :sha384, :sha512, :sha256_sha256
config :merkel, hash_algorithm: :sha384- Configure the hash function to pass in a &Mod.fun/1 (if necessary)
# Override in config.exs
# Function must be specified using &Mod.fun/arity format
# Function have arity 1, accepting a binary and then returning a binary
# Note if you have a custom function like:
# &(:crypto.hash(:ripemd160, :crypto.hash(:sha256, &1)) |> Base.encode16(case: :lower))
# Wrap it in a module and function then pass the MFA
config :merkel, hash_function: &MyMod.ripemd160_sha256_hash/1
# another
config :merkel, hash_function: &Merkel.Crypto.sha256_2_hash/1
Install
- Add to mix dependency list in mix.exs
def deps do
[{:merkel, "~> 1.0"}]
endProperty Testing
Now uses PropCheck, see the interactive iex steps below:
$ MIX_ENV="test" iex -S mix
iex(1)> ExUnit.start()
:ok
iex(2)> c "test/test_data_helper.exs"
[Merkel.TestDataHelper]
iex(3)> c "test/test_helper.exs"
[Merkel.TestHelper]
iex(4)> c "test/merkel/tree_prop_test.exs"
[Merkel.TreePropTest]iex(5)> :proper_gen.pick(Merkel.TreePropTest.generate_tree(:option_min_four_tree))
{:ok,
{#Merkel.Tree<{11,
{"1c0b3fd4c855c73be46674274fe93aadbce778abe658f8dc7609b32e0009505b",
"<=Pa..>", 4,
{"4fd4..", "<=5n..>", 3,
{"5281..", "<=1K..>", 2,
{"b52a..", "<=..>", 1, {"e3b0..", "", 0}, {"3bb4..", "1K1VUQe", 0}},
{"c508..", "5nUn5j", 0}},
{"63ab..", "<=Ab..>", 2,
{"7d90..", "<=8..>", 1, {"2c62..", "8", 0}, {"9e7d..", "AbO5yut", 0}},
{"37a8..", "PayBYPCDG", 0}}},
{"cf50..", "<=o..>", 3,
{"20fc..", "<=lL..>", 2,
{"be7c..", "<=W7..>", 1, {"a025..", "W7A", 0},
{"47e9..", "lLHFfoBPEd", 0}}, {"65c7..", "o", 0}},
{"0d48..", <<163, 242>>, 1,
{"6e20..", <<163, 242, 62, 183, 209, 8, 25, 113, 160>>, 0},
{"6033..", <<194, 176, 11, 189, 137, 14, 47, 129, 12, 94>>, 0}}}}}>,
[
{"1K1VUQe", -1.3789317543904047},
{"8", 3},
{"5nUn5j", 26.852740399500124},
{"o", -1.0160044166486373},
{"", :"\x92"},
{<<163, 242, 62, 183, 209, 8, 25, 113, 160>>, 7.496176300512326},
{"W7A", 8},
{"PayBYPCDG", -4},
{"lLHFfoBPEd", "wy"},
{<<194, 176, 11, 189, 137, 14, 47, 129, 12, 94>>, 73.01214022127897},
{"AbO5yut", :"w\x05"}
],
[
"",
"1K1VUQe",
"5nUn5j",
"8",
"AbO5yut",
"PayBYPCDG",
"W7A",
"lLHFfoBPEd",
"o",
<<163, 242, 62, 183, 209, 8, 25, 113, 160>>,
<<194, 176, 11, 189, 137, 14, 47, 129, 12, 94>>
], "1K1VUQe", 11}}iex(6)> :proper_gen.pick(Merkel.TreePropTest.generate_tree(:option_min_one_tree))
{:ok,
{#Merkel.Tree<{4,
{"9b5378f0ca095b1e106c795d16a93ca34f9c6d851e37a300441707e9084d8b6c",
"<=qd..>", 2,
{"5f0c..", "<=a4..>", 1, {"9045..", "a4y9MVW", 0}, {"8a60..", "qdKLAH", 0}},
{"0c3b..", "<=u..>", 1, {"0bfe..", "u", 0}, {"63ce..", "xRMVGkW7Mu", 0}}}}>,
[
{"xRMVGkW7Mu", :"O\x80Ëסe"},
{"qdKLAH", :"=8Ôb\d"},
{"a4y9MVW", "y"},
{"u", -6}
], ["a4y9MVW", "qdKLAH", "u", "xRMVGkW7Mu"], "xRMVGkW7Mu", 4}}iex(7)> use PropCheck
PropCheck.TargetedPBTiex(8)> sample_shrink(Merkel.TreePropTest.unique_kv_pairs_list())
[{<<"0VWd29TyU">>,-15},
{<<"y">>,5},
{<<"nl0z">>,'³'},
{<<"o">>,-71},
{<<"XBKJ4pa2mU">>,-2.112760294833219},
{<<"5l8OT">>,4}]
[{<<"0VWd29TyU">>,-15},{<<"y">>,5},{<<"nl0z">>,'³'}]
[{<<"y">>,5},{<<"nl0z">>,'³'}]
[{<<"nl0z">>,'³'}]
[{<<"nl">>,'³'}]
[{<<"l">>,'³'}]
[{<<"A">>,'³'}]
[{<<"A">>,1}]
[{<<"A">>,0}]
:okiex(9)> generator = fn() -> Merkel.TreePropTest.kv_pairs_list(:atleast_four) end
#Function<21.91303403/0 in :erl_eval.expr/5>iex(10)> sample_shrink(Merkel.TreePropTest.unique_kv_pairs_list(generator))
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"TOLd8DWOnS">>,14.829839030779532},
{<<"G1FvfvgK5">>,4.649627366501582},
{<<"eKkB">>,11.123432807491671},
{<<"dA1rL">>,0.44012177370998223},
{<<"c1wd1Cy4L1">>,'\237Tð#\tL'},
{<<"½Rò(Ü-\v">>,<<"lbpiyuwf">>},
{<<"Q4Xq">>,-3.2102621792071826},
{<<"A">>,13},
{<<"2rUUiL">>,8},
{<<24,168>>,''}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"TOLd8DWOnS">>,14.829839030779532},
{<<"G1FvfvgK5">>,4.649627366501582},
{<<"eKkB">>,11.123432807491671},
{<<"dA1rL">>,0.44012177370998223},
{<<"c1wd1Cy4L1">>,'\237Tð#\tL'},
{<<"½Rò(Ü-\v">>,<<"lbpiyuwf">>}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"TOLd8DWOnS">>,14.829839030779532},
{<<"G1FvfvgK5">>,4.649627366501582},
{<<"eKkB">>,11.123432807491671},
{<<"dA1rL">>,0.44012177370998223}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"TOLd8DWOnS">>,14.829839030779532},
{<<"eKkB">>,11.123432807491671},
{<<"dA1rL">>,0.44012177370998223}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"TOLd8DWOnS">>,14.829839030779532},
{<<"dA1rL">>,0.44012177370998223}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"TOLd8DWOnS">>,14.829839030779532},
{<<"dA1">>,0.44012177370998223}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"TOLd8DWOnS">>,14.829839030779532},
{<<"A1">>,0.44012177370998223}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"TOLd8DWOnS">>,14.829839030779532},
{<<"1">>,0.44012177370998223}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"TOLd8DWOnS">>,14.829839030779532},
{<<"A">>,0.44012177370998223}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"TOLd8DWOnS">>,14.829839030779532},
{<<"A">>,0}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"TOLd8">>,14.829839030779532},
{<<"A">>,0}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"TOL">>,14.829839030779532},
{<<"A">>,0}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"OL">>,14.829839030779532},
{<<"A">>,0}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"L">>,14.829839030779532},
{<<"A">>,0}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"B">>,14.829839030779532},
{<<"A">>,0}]
[{<<"SpOFfjnNi">>,<<"a">>},
{<<"46xcvesqV">>,<<"4|)ÓX">>},
{<<"B">>,0},
{<<"A">>,0}]
[{<<"SpOFfjnNi">>,<<"a">>},{<<"46xcv">>,<<"4|)ÓX">>},{<<"B">>,0},{<<"A">>,0}]
[{<<"SpOFfjnNi">>,<<"a">>},{<<"46x">>,<<"4|)ÓX">>},{<<"B">>,0},{<<"A">>,0}]
[{<<"SpOFfjnNi">>,<<"a">>},{<<"6x">>,<<"4|)ÓX">>},{<<"B">>,0},{<<"A">>,0}]
[{<<"SpOFfjnNi">>,<<"a">>},{<<"x">>,<<"4|)ÓX">>},{<<"B">>,0},{<<"A">>,0}]
[{<<"SpOFfjnNi">>,<<"a">>},{<<"C">>,<<"4|)ÓX">>},{<<"B">>,0},{<<"A">>,0}]
[{<<"SpOFfjnNi">>,<<"a">>},{<<"C">>,29},{<<"B">>,0},{<<"A">>,0}]
[{<<"SpOFfjnNi">>,<<"a">>},{<<"C">>,0},{<<"B">>,0},{<<"A">>,0}]
[{<<"SpOFf">>,<<"a">>},{<<"C">>,0},{<<"B">>,0},{<<"A">>,0}]
[{<<"SpO">>,<<"a">>},{<<"C">>,0},{<<"B">>,0},{<<"A">>,0}]
[{<<"pO">>,<<"a">>},{<<"C">>,0},{<<"B">>,0},{<<"A">>,0}]
[{<<"O">>,<<"a">>},{<<"C">>,0},{<<"B">>,0},{<<"A">>,0}]
[{<<"D">>,<<"a">>},{<<"C">>,0},{<<"B">>,0},{<<"A">>,0}]
[{<<"D">>,-9},{<<"C">>,0},{<<"B">>,0},{<<"A">>,0}]
[{<<"D">>,0},{<<"C">>,0},{<<"B">>,0},{<<"A">>,0}]
:okiex(11)> produce(such_that {_x1, _x2, _x3, _x4, size}
<- Merkel.TreePropTest.generate_tree(:option_min_one_tree), when: size == 3)
{:ok,
{#Merkel.Tree<{3,
{"a28b2edeeb8e72881763e0ece89c257dc7a317e2bfcd53aefd48ed17059ddfda",
"<=oE..>", 2,
{"d890..", "<=7F..>", 1, {"e818..", "7FjDV", 0}, {"cf21..", "oEr", 0}},
{"95df..", "tgSA 4Nz", 0}}}>,
[
{"oEr", -0.057744741577119},
{"tgSA 4Nz", -6.749199934830595},
{"7FjDV", :"5Ô\f\x96"}
], ["7FjDV", "oEr", "tgSA 4Nz"], "oEr", 3}}Thanks!
Thanks for the great Erlang/Elixir/Go/Clojure/Java open source merkle tree related projects for the inspiration
Most notably merklet and gb_merkle_trees
Cheers Bibek Pandey
