FLex

A toolkit for fuzzy logic, this library includes functions to make fuzzy sets, variables and rules for creating a Fuzzy Logic System (FLS).

The goal of FLex is to easily design and efficiently operate fuzzy logic controllers without relying on external libraries.

Index

Features

The following list is the current supported backend for each component of the FLS:

NOTE: All systems are single output.

Installation

The package can be installed by adding flex to your list of dependencies in mix.exs:

def deps do
  [
    {:flex, "~> 0.1.0"}
  ]
end

Usage

Sets

Step 1: Define all fuzzy sets with Flex.Set.new/1, the following options are require:

t_h = Flex.Set.new(tag: "too hot", mf_type: "saturation", mf_params: [-2, 0, -4])
j_r = Flex.Set.new(tag: "just right", mf_type: "triangle", mf_params: [-2, 0, 2])
t_c = Flex.Set.new(tag: "too cold", mf_type: "shoulder", mf_params: [0, 2, 4])

g_h = Flex.Set.new(tag: "getting hotter", mf_type: "saturation", mf_params: [-5, 0, -10])
n_c = Flex.Set.new(tag: "no change", mf_type: "triangle", mf_params: [-5, 0, 5])
g_c = Flex.Set.new(tag: "getting colder", mf_type: "shoulder", mf_params: [0, 5, 10])

co = Flex.Set.new(tag: "cool", mf_type: "saturation", mf_params: [-50, 0, -100])
d_n = Flex.Set.new(tag: "do nothing", mf_type: "triangle", mf_params: [-50, 0, 50])
he = Flex.Set.new(tag: "heat", mf_type: "shoulder", mf_params: [0, 50, 100])

Variables

Step 2: Define all fuzzy variables with Flex.Variable.new/1, the following options are required:

fuzzy_sets = [t_h, j_r, t_c]
error = Flex.Variable.new(tag: "error", fuzzy_sets: fuzzy_sets, type: :antecedent, range: -4..4)

fuzzy_sets = [g_h, n_c, g_c]
dt_error = Flex.Variable.new(tag: "dt_error", fuzzy_sets: fuzzy_sets, type: :antecedent, range: -10..10)

fuzzy_sets = [co, d_n, he]
output = Flex.Variable.new(tag: "output", fuzzy_sets: fuzzy_sets, type: :consequent, range: -100..100)

Rules

Currently there are two types of syntax for defining the rules statement:

  import Flex.Rule
  r1 =
    {{{{"error", "too hot", "~>"}, {"dt_error", "getting colder", "~>"}, "&&&"}, "output",
      ">>>"}, "cool", "~>"}

  r2 =
    {{{{"error", "just right", "~>"}, {"dt_error", "getting colder", "~>"}, "&&&"}, "output",
      ">>>"}, "heat", "~>"}

  r3 =
    {{{{"error", "too cold", "~>"}, {"dt_error", "getting colder", "~>"}, "&&&"}, "output",
      ">>>"}, "heat", "~>"}

  r4 =
    {{{{"error", "too hot", "~>"}, {"dt_error", "no change", "~>"}, "&&&"}, "output", ">>>"},
      "cool", "~>"}

  r5 =
    {{{{"error", "just right", "~>"}, {"dt_error", "no change", "~>"}, "&&&"}, "output", ">>>"},
      "do nothing", "~>"}

  r6 =
    {{{{"error", "too cold", "~>"}, {"dt_error", "no change", "~>"}, "&&&"}, "output", ">>>"},
      "heat", "~>"}

  r7 =
    {{{{"error", "too hot", "~>"}, {"dt_error", "getting hotter", "~>"}, "&&&"}, "output",
      ">>>"}, "cool", "~>"}

  r8 =
    {{{{"error", "just right", "~>"}, {"dt_error", "getting hotter", "~>"}, "&&&"}, "output",
      ">>>"}, "cool", "~>"}

  r9 =
    {{{{"error", "too cold", "~>"}, {"dt_error", "getting hotter", "~>"}, "&&&"}, "output",
      ">>>"}, "cool", "~>"}

  rule1 = Flex.Rule.new(statement: r1, consequent: output.tag, antecedent: [error.tag, dt_error.tag])
  rule2 = Flex.Rule.new(statement: r2, consequent: output.tag, antecedent: [error.tag, dt_error.tag])
  rule3 = Flex.Rule.new(statement: r3, consequent: output.tag, antecedent: [error.tag, dt_error.tag])
  rule4 = Flex.Rule.new(statement: r4, consequent: output.tag, antecedent: [error.tag, dt_error.tag])
  rule5 = Flex.Rule.new(statement: r5, consequent: output.tag, antecedent: [error.tag, dt_error.tag])
  rule6 = Flex.Rule.new(statement: r6, consequent: output.tag, antecedent: [error.tag, dt_error.tag])
  rule7 = Flex.Rule.new(statement: r7, consequent: output.tag, antecedent: [error.tag, dt_error.tag])
  rule8 = Flex.Rule.new(statement: r8, consequent: output.tag, antecedent: [error.tag, dt_error.tag])
  rule9 = Flex.Rule.new(statement: r9, consequent: output.tag, antecedent: [error.tag, dt_error.tag])

  rules = [rule1, rule2, rule3, rule4, rule5, rule6, rule7, rule8, rule9]

Note: You need to import Flex.Rule module.

System

Step 4: Define FLS with Flex.System.start_link/1 or Flex.System.start_link/2 if you want to overwrite the GenServer options; the following options are require:

  {:ok, s_pid} = Flex.System.start_link(antecedent: [error, dt_error], consequent: output, rules: rules)

Step 5: Fit the FLS with a input vector using Flex.System.compute/2.

  result = Flex.System.compute(s_pid, [-1, -2.5])
  #result ~= -63.4 aprox

In test/system_test.exs there is an example of use, that is based on this example.

ANFIS

An adaptive network-based fuzzy inference system (ANFIS) is a kind of artificial neural network that is based on Takagi–Sugeno fuzzy inference system, this implementation use backpropagation, only Gaussian & Generalized Bell Membership functions are allowed. In examples/anfis_demo1.exs there is an example of use.

Documentation

The docs can be found at https://hexdocs.pm/flex.

Contributing

License

See LICENSE.

TODO
