Crank

Crank

License: MIT

Crank.turn(machine, event) — a pure function call that advances a state machine. No process required. Promote to a supervised :gen_statem when needed. Same module, no rewrite.

Crank is opinionated: it is a Moore state machine library. Outputs are a function of the state, not of the edge that arrived there.

Quick start

defmodule MyApp.VendingMachine do
  use Crank

  @impl true
  def start(opts) do
    {:ok, :idle, %{price: opts[:price] || 100, balance: 0, selection: nil}}
  end

  # Transitions are pure state computation. No effects, ever.
  @impl true
  def turn({:coin, amount}, :idle, memory) do
    {:next, :accepting, %{memory | balance: amount}}
  end

  def turn({:coin, amount}, :accepting, memory) do
    {:stay, %{memory | balance: memory.balance + amount}}
  end

  def turn({:select, item}, :accepting, %{balance: b, price: p} = memory)
      when b >= p do
    {:next, :dispensing, %{memory | selection: item}}
  end

  def turn(:dispensed, :dispensing, memory) do
    {:next, :idle, %{memory | balance: 0, selection: nil}}
  end

  # Effects live on states. Timeouts attach to the state that has them,
  # not to the edge that arrived at them.
  @impl true
  def wants(:accepting, _memory), do: [{:after, 60_000, :timeout_refund}]
  def wants(:dispensing, _memory), do: [{:after, 5_000, :jam}]
  def wants(_state, _memory), do: []

  # What outside callers see. Pure projection of (state, memory).
  @impl true
  def reading(:idle, _memory), do: %{status: :idle}
  def reading(:accepting, memory), do: %{status: :accepting, balance: memory.balance}
  def reading(:dispensing, memory), do: %{status: :dispensing, item: memory.selection}
end

Pure usage

No process, no setup, no cleanup:

machine =
  MyApp.VendingMachine
  |> Crank.new(price: 75)
  |> Crank.turn({:coin, 25})
  |> Crank.turn({:coin, 50})
  |> Crank.turn({:select, "A3"})

machine.state         #=> :dispensing
machine.wants         #=> [{:after, 5_000, :jam}]
Crank.reading(machine) #=> %{status: :dispensing, item: "A3"}

Process usage

Same module. Supervised :gen_statem with real timers and telemetry:

{:ok, pid} = Crank.Server.start_link(MyApp.VendingMachine, price: 75)
Crank.Server.turn(pid, {:coin, 25})
#=> %{status: :accepting, balance: 25}

Crank.Server.reading(pid)
#=> %{status: :accepting, balance: 25}

Crank.Server.turn/2 advances the machine and replies with the new reading. Crank.Server.reading/1 projects without advancing. Same module, different caller.

The vocabulary

Term Meaning
turn/3 The transition callback you write. Pure state computation.
wants/2 What the state declares on arrival. Timeouts, sends, telemetry, internal events. Optional.
reading/2 What outside callers observe. Projection of (state, memory). Optional.
memory Cross-state data carried through every turn.
state Current state. Any term — atom, struct, tagged tuple.
engine Lifecycle: :running or {:off, reason}.

The user's verb is turn in both modes — Crank.turn/2 in pure mode, Crank.Server.turn/2 in process mode. The library is called Crank because you're cranking a machine; the verb for the operation is turn for consistency with the callback.

The struct

After each turn/2, the returned %Crank{} has five fields:

machine.wants is a materialised cache of the wants/2 callback. The library guarantees the invariant machine.wants == module.wants(machine.state, machine.memory) after new/2, after every turn/2 (regardless of :next, :stay, or :stop), and after resume/1. The pure core never executes wants; Crank.Server interprets the declared list on every {:next, ...} arrival.

Return values from turn/3

{:next, new_state, new_memory}     # move to a different state
{:stay, new_memory}                # same state, updated memory
:stay                              # nothing changes
{:stop, reason, new_memory}        # shut down the machine

No action tuples. No effects. turn/3 is pure state computation; this is the structural enforcement of the Moore discipline.

Want types

wants/2 returns a list of these:

Want Effect
{:after, ms, event} Anonymous state timeout. Fire event after ms if the state hasn't changed. One per state; auto-cancels on state-value change.
{:after, name, ms, event} Named generic timeout. Multiple may run concurrently. Cancelled explicitly with {:cancel, name}.
{:cancel, name} Cancel a named timeout. No-op if no such timer runs.
{:next, event} Inject an internal event, processed before any queued external event.
{:send, dest, message} Send message to dest (pid, registered name, or {name, node}). Fire-and-forget.
{:telemetry, name, measurements, metadata} Emit a telemetry event.

Moore, not Mealy

Crank is opinionated about the shape of its state machines. Two classical shapes exist:

Crank is Moore. turn/3 computes state. wants/2 declares effects on arrival at a state. You cannot attach an effect to an edge — the API does not provide the hook.

Why Moore

Moore machines are easier to reason about because the question "what does this state do?" has a single answer you can read in one place. In Mealy, the same question requires scanning every transition that arrives at that state and assembling the pieces.

The most successful stateful abstraction in Elixir, Phoenix LiveView, is Moore-shaped. handle_event/3 updates socket.assigns (pure state change). render/1 projects the UI from assigns — render = f(assigns), with no access to the event that caused the assigns to change. The UI is a function of state, full stop. That discipline is a large part of why LiveView is ergonomic: the rendering question reduces to "given this state, what should be on screen?"

A speculation on gen_statem

:gen_statem is the standard-library state machine in OTP. It is powerful and well-built, but has never achieved the popularity of GenServer in the Elixir community. One plausible reason: its default grain is Mealy. A transition clause returns {:next_state, NewState, Data, Actions} — the actions list is an edge-attached emission. To read what a state does on arrival, you scan the handlers that transition into it. The state-enter callback mode exists, but it is opt-in and the documentation treats it as advanced.

A library that makes Moore the only option — where the question "what does this state do?" maps to one wants/2 clause and one reading/2 clause — may be closer to what most Elixir developers actually want from a state machine abstraction. Crank is an attempt to test that hypothesis.

Why Crank exists

Business logic is states and transitions. A customer is :prospect, :active, :churning, :dormant. A policy is :quoted, :bound, :active, :lapsed. A submission is :received, :validating, :eligible, :declined. Business rules are transition rules: "can't bind without quoting first,""when the underwriter approves, move to eligible."

Every business rule answers: given this state and this event, what happens next? That is the definition of a finite state machine. The question is whether the state machine is explicit in the code or hidden inside a GenServer with scattered %{status: ...} pattern matches.

A GenServer with handle_call clauses that check state.status is an implicit state machine. A Crank module is an explicit one. Both encode the same rules; one is readable.

:gen_statem exists in OTP but is rarely reached for because its Mealy grain makes reading and writing more expensive than GenServer with a status atom. Crank separates state-machine logic from process concerns (same module runs pure or supervised) and enforces Moore discipline structurally.

How Crank compares to GenServer

José Valim's consistent advice: start simple, promote to complex when needed. Plain functions before GenServer. GenServer before :gen_statem.

Crank's pure mode is simpler than GenServer. Crank.turn(machine, event) is a function call that returns a struct. No start_link. No mailbox. No supervision tree. No process lifecycle.

Pure function  (Crank.turn/2)
       ↓  promotion when you need supervision, timeouts, telemetry
gen_statem process  (Crank.Server)

The promotion path is built in. Same module, different caller.

Struct-per-state

The standard Elixir approach uses one struct with a :status atom and every field present in every state. That is what DDD calls an anemic domain model — the shape does not encode the rules.

Crank supports an alternative: each state is its own struct.

defmodule Idle,       do: defstruct []
defmodule Accepting,  do: defstruct [:balance]
defmodule Dispensing, do: defstruct [:balance, :selection]

A %Dispensing{} cannot have a change field because the struct does not define one. Pattern-matching on the struct type gives the state and its data in one destructure:

def turn({:select, item}, %Accepting{balance: b}, memory) when b >= memory.price do
  {:next, %Dispensing{balance: b, selection: item}, memory}
end

State-specific data lives in the struct. Cross-cutting concerns live in memory. Elixir's set-theoretic type system will eventually check these unions at compile time; Crank.Examples.Submission is designed for that.

Telemetry

Crank.Server emits four events automatically:

Wants can also emit user-defined telemetry via {:telemetry, name, measurements, metadata}.

Persistence

%Crank{} is a plain immutable struct. Persisting it is writing a map; restoring it is reading one.

# Capture
snapshot = Crank.snapshot(machine)
#=> %{module: MyApp.VendingMachine, state: :accepting, memory: %{...}}

# Restore (pure)
machine = Crank.resume(snapshot)

# Restore (supervised process)
{:ok, pid} = Crank.Server.resume(snapshot)

Snapshots are plain maps — portable across serialization boundaries. Pure resume/1 populates the wants cache per the invariant but executes nothing. Crank.Server.resume/2 additionally re-executes wants, re-arming timers and re-emitting sends; recipients should be idempotent or the effect belongs in a saga with durable delivery state. Both emit [:crank, :resume] telemetry.

Event-sourcing works the same as snapshot-per-transition: attach a telemetry handler to [:crank, :transition], write the event, and fold events through Crank.turn/2 on restore.

Coordinating multiple machines

When one machine's outcome drives another — an order completes, a payment fires, fulfillment starts — that coordination is itself a state machine. DDD calls this a process manager or saga. A saga has states (awaiting payment, awaiting fulfillment), events (payment succeeded, fulfillment completed), and transitions. That is another Crank module.

The saga doesn't contain the business logic of payment or fulfillment. It orchestrates them. Each step sends an event to another state machine and waits for the response.

State machines all the way down. The domain objects are state machines. The coordination between them is a state machine. The pattern scales because the abstraction is the same at every level.

Testing machines that interact

A common objection to pure state machines: "Sure, one machine in isolation is easy to test. But my real system has an order machine that triggers a payment machine that triggers a fulfillment machine. You can't test that without processes."

You can. The interaction between machines is a function over structs. Turn both of them in one test, assert on both:

test "payment confirmation advances the order" do
  order   = Crank.new(MyApp.Order) |> Crank.turn(:submit)
  payment = Crank.new(MyApp.Payment) |> Crank.turn({:charge, order.memory.total})

  assert payment.state == :confirmed

  order = Crank.turn(order, {:payment_confirmed, payment.memory.txn_id})
  assert order.state == :awaiting_fulfillment
end

Two machines. One test. No processes, no mailboxes, no start_link, no sleeping, no eventually helpers.

Composing work

Three supplementary modules ship with Crank for composing effects and multi-machine work:

Quick taste:

order   = Crank.new(MyApp.Order)
payment = Crank.new(MyApp.Payment)

Crank.Turns.new()
|> Crank.Turns.turn(:order, order, :submit)
|> Crank.Turns.turn(:payment, payment,
     fn %{order: o} -> {:charge, o.memory.total} end)
|> Crank.Turns.apply()
#=> {:ok, %{order: %Crank{...}, payment: %Crank{...}}}

The full guide — including failure shapes, pure/process symmetry, the builder surface, and the saga-vs-Turns distinction — is in the Composing Work guide.

Authorization

Authorization belongs in the application service that calls Crank.turn/2, not inside turn/3. A Crank aggregate answers "what happens given this event?" — not "is this caller allowed to send this event?" Keeping policy outside the aggregate preserves the pure-core property (same input, same output, no environment dependency) and matches the DDD convention that aggregates enforce invariants, while application services enforce access.

A typical wiring:

def place_order(caller, order_id, event) do
  with :ok <- authorize(caller, order_id, event),
       {:ok, machine} <- load(order_id) do
    updated = Crank.turn(machine, event)
    persist(updated)
    {:ok, Crank.reading(updated)}
  end
end

If the machine needs to record the caller (for audit, for domain rules like "only the submitter can cancel"), the caller identity is part of the event payload, not a separate authorization concern: Crank.turn(machine, {:cancel, by: user_id}).

Installation

def deps do
  [
    {:crank, "~> 1.0"}
  ]
end

Documentation

License

MIT
