Crank

Crank.crank(machine, event) -- a pure function call that advances a state machine. No process required. Promote to a supervised gen_statem when needed. Same module, no rewrite.

Quick start

Define a state machine by implementing the Crank behaviour (an interface contract -- define specific functions, Crank calls them):

defmodule MyApp.VendingMachine do
  use Crank

  @impl true
  def init(opts), do: {:ok, :idle, %{price: opts[:price] || 100, balance: 0, stock: 10}}

  @impl true
  def handle({:coin, amount}, :idle, data) do
    {:next_state, :accepting, %{data | balance: amount}}
  end

  def handle({:coin, amount}, :accepting, data) do
    {:next_state, :accepting, %{data | balance: data.balance + amount}}
  end

  def handle({:select, _item}, :accepting, %{balance: bal, price: price} = data)
      when bal >= price do
    {:next_state, :dispensing, data, [{:state_timeout, 5_000, :jam_timeout}]}
  end

  def handle(:dispensed, :dispensing, %{balance: bal, price: price} = data) do
    remaining = data.stock - 1
    change = bal - price

    cond do
      change > 0 ->
        {:next_state, :making_change, %{data | stock: remaining, balance: change}}
      remaining == 0 ->
        {:next_state, :out_of_stock, %{data | stock: 0, balance: 0}}
      true ->
        {:next_state, :idle, %{data | stock: remaining, balance: 0}}
    end
  end

  def handle(:change_returned, :making_change, data) do
    if data.stock == 0 do
      {:next_state, :out_of_stock, %{data | balance: 0}}
    else
      {:next_state, :idle, %{data | balance: 0}}
    end
  end

  def handle(:restock, :out_of_stock, data) do
    {:next_state, :idle, %{data | stock: 10}}
  end

  def handle(:cancel, :accepting, data) do
    {:next_state, :making_change, data}
  end
end

Pure usage

No process, no setup, no cleanup:

machine =
  MyApp.VendingMachine
  |> Crank.new(price: 75)
  |> Crank.crank({:coin, 25})
  |> Crank.crank({:coin, 50})
  |> Crank.crank({:select, "A3"})

machine.state   #=> :dispensing
machine.effects #=> [{:state_timeout, 5_000, :jam_timeout}]

Process usage

Same module, now supervised with timeouts and telemetry:

{:ok, pid} = Crank.Server.start_link(MyApp.VendingMachine, price: 75)
Crank.Server.cast(pid, {:coin, 25})

Same module. Same functions. Two callers.

What just happened

The module above is a complete state machine. init/1 returned the starting state and initial data. Each handle/3 clause declared one transition -- this event, in this state, produces this outcome. Crank.crank/2 called those functions and returned a new struct. The sections below explain each part.

Callback signature

The primary callback is handle/3. Crank calls it every time an event arrives, passing the event, the current state, and the accumulated data. It returns a tuple describing what happens next:

def handle(event, state, data)

def handle({:coin, amount}, :accepting, data) do
  {:next_state, :accepting, %{data | balance: data.balance + amount}}
end

handle/3 drops event_type. In pure mode that's fine -- Crank.crank/2 only delivers internal events, so there's nothing to distinguish. Under Crank.Server, though, the same event payload can arrive as :cast, {:call, from}, :info, :state_timeout, and more, and handle/3 sees them all identically. If you need to tell a cast from a call, send a reply, or match on a timeout, use handle_event/4. It matches gen_statem's handle_event_function callback mode exactly:

def handle_event(event_type, event_content, state, data)

If a module exports handle_event/4, Crank uses it instead of handle/3. When a module defines both, add a catch-all delegation:

# Server-only: reply to synchronous calls
def handle_event({:call, from}, :status, state, data) do
  {:keep_state, data, [{:reply, from, state}]}
end

# Everything else delegates to handle/3
def handle_event(_, event, state, data), do: handle(event, state, data)

The struct

After each crank/2 call, the returned %Crank.Machine{} struct has five fields:

• module -- the callback module (so the struct knows which functions to call)
• state -- the current state (any Elixir term -- atoms, structs, tuples)
• data -- whatever init/1 and handle/3 have accumulated
• effects -- side effects from the last transition, stored as data (never executed)
• status -- :running or {:stopped, reason}

Return values

Every handle/3 clause returns a tuple that tells Crank what to do next:

• {:next_state, new_state, new_data} -- move to a different state
• {:next_state, new_state, new_data, actions} -- move and declare side effects
• {:keep_state, new_data} -- stay in the same state, update the data
• {:keep_state, new_data, actions} -- stay and declare side effects
• :keep_state_and_data -- nothing changes
• {:keep_state_and_data, actions} -- nothing changes but declare side effects
• {:stop, reason, new_data} -- shut down the machine

These match gen_statem's return values exactly. gen_statem calls them "actions." Crank stores them in the machine.effects field. Same thing, two names.

Effects as data

When a callback returns actions, the pure core stores them in machine.effects as inert data. It never executes them. Crank.Server executes them via gen_statem.

def handle({:select, _item}, :accepting, %{balance: bal, price: price} = data)
    when bal >= price do
  {:next_state, :dispensing, data, [{:state_timeout, 5_000, :jam_timeout}]}
end

machine = Crank.crank(machine, {:select, "A3"})
machine.effects
#=> [{:state_timeout, 5_000, :jam_timeout}]

Each crank/2 call replaces effects. They don't accumulate across pipeline stages.

Enter callbacks

Optional. Crank calls on_enter/3 after a state change, passing the old state, the new state, and the data:

@impl true
def on_enter(_old_state, _new_state, data) do
  {:keep_state, Map.put(data, :transitioned_at, System.monotonic_time())}
end

Stopped machines

{:stop, reason, data} sets machine.status to {:stopped, reason}. Further cranks raise Crank.StoppedError. Use crank!/2 in tests to raise immediately on stop results.

Unhandled events

No catch-all. Unhandled events crash with FunctionClauseError. This is deliberate -- a state machine that silently ignores events is hiding bugs. Let it crash; let the supervisor handle it.

Why Crank exists

That's the full API. The rest of this document explains why Crank exists, how it compares to GenServer, and where state machines fit in domain-driven design.

The problem Crank solves

State machine logic in Erlang started as plain functions calling functions. Each state was a function. The data available in each state was whatever that function received -- nothing more. The logic was portable and testable because it was just functions.

Two things happened on the way to modern Elixir:

1. Data scoping disappeared. In early Erlang, locked/2 could only see what locked/2 was given. In a GenServer (Elixir's primary process abstraction) with %{status: :dispensing, balance: 100, selection: nil, change: nil}, every handler sees every field. Nothing prevents reading change when the status is :dispensing.

2. State machine logic became inseparable from processes.gen_fsm (Erlang's first formal state machine behaviour, late 1990s) coupled logic to a process. gen_statem (its replacement, 2016) continued that coupling. GenServer dropped state machine primitives entirely. Each step moved further from logic that could be called directly.

Crank separates the two concerns that got fused together: state machine logic and process lifecycle.

The pure core, Crank.crank/2, takes a struct and an event and returns a new struct. No process, no mailbox, no side effects. The process shell, Crank.Server, wraps the same module in gen_statem (Erlang's built-in state machine process) when timeouts, supervision, and telemetry are needed. Same logic, both modes.

For data scoping, Crank supports struct-per-state -- each state is its own struct with exactly the fields that exist in that state (see Struct-per-state below). A %Dispensing{} struct can't have a change field because the field doesn't exist on that struct. The types enforce the invariants.

How Crank compares to GenServer

José Valim's consistent advice: start simple, promote to complex when needed. Plain functions before GenServer. GenServer before gen_statem.

Crank's pure mode is simpler than GenServer. Crank.crank(machine, event) is a function call that returns a struct. No start_link. No mailbox. No supervision tree. No process lifecycle.

Pure function (Crank.crank/2) → GenServer → gen_statem (Crank.Server)
       simplest                                     most powerful

The promotion path is built in. Start with Crank.crank/2 (pure, no process). Promote to Crank.Server (supervised gen_statem) when timeouts, supervision, or replies are needed. The promotion is a deployment decision, not a rewrite. Same module, same logic, different caller.

Most Elixir developers use GenServer with a %{status: :accepting} field and pattern match on it in their handle_call and handle_cast clauses. That IS a state machine. It's just not a formal one.

The Elixir ecosystem has spent a decade building out its infrastructure: Ecto for persistence, Phoenix for web, Oban for background jobs, Broadway for data pipelines, Bandit for HTTP. Caches, connection pools, pubsub brokers, HTTP clients -- all built, all mature, all excellent. That infrastructure exists to support one thing: the domain model (the data structures and rules that represent what a system actually does, independent of databases or web frameworks).

As the infrastructure layer matures and gets solved, what remains is the domain model. And a domain model IS states and transitions.

A customer is in a state: prospect, active, churning, dormant. A submission is in a state: received, validating, eligible, declined. A policy is in a state: quoted, bound, active, lapsed, renewed.

Business rules ARE transition rules: "can't bind without quoting first," "when the underwriter approves, move from review to eligible." The states are the domain model. The transitions are the business logic. Together, they're a state machine.

Every business rule answers one question: given this state and this event, what happens next? That's the definition of a finite state machine. The question was never whether a domain has a state machine in it. It always does. The question is whether it's explicit or implicit.

A GenServer with scattered pattern matches across handle_call clauses is a domain model that hides itself. A Crank module where each handle/3 clause declares a state, an event, and a transition is a domain model that's honest about what it is. Both are state machines. One is readable.

The reason domain models got hidden inside GenServers was cost. gen_statem added ceremony -- callback modes, process coupling, untestable runtime integration. Crank eliminates that cost. A handle/3 clause is no more complex than a handle_call with pattern matching on state.status. Explicit is now as cheap as implicit.

Domain functions serve the state machine

A common objection: "My domain logic is too complex for a state machine. I have pricing engines, eligibility rules, validation pipelines."

These aren't alternatives to the state machine. They're tools it uses. A pricing engine is a function called insidehandle/3:

def handle(:calculate_premium, %Quoted{} = state, data) do
  premium = PricingEngine.calculate(data.risk_factors, data.coverage)
  {:next_state, %Quoted{state | premium: premium}, data}
end

The pricing engine doesn't decide what state to transition to. The state machine decides that. The pricing engine computes a value. Decision tables, eligibility rules, validation pipelines -- they all live inside handle/3 clauses, called when the state machine determines they're relevant. The state machine is the orchestrator. Everything else is a helper.

In domain-driven design, this relationship is called an aggregate -- a cluster of related data and rules treated as a single unit, with one entry point controlling all changes. Outside code doesn't reach into the pricing engine directly. It sends an event to the aggregate, and the aggregate decides which internal functions to invoke based on its current state. The state machine IS the aggregate root.

Recognizing the state machine you already have

Object-oriented code with status checks is already a state machine:

class Policy
  def bind!
    raise "Can't bind without a quote" unless status == :quoted
    raise "Can't bind a declined policy" if status == :declined
    self.status = :bound
    notify_underwriter
  end
end

Every guard clause is a transition rule. Every status check is a state. Every method that changes status is an event handler. This is a state machine -- spread across methods instead of declared in one place.

When the rules are simple, it works. When there are fifteen statuses and forty methods that each check three preconditions, the implicit machine becomes unreadable. No one can answer "what are all the ways a policy reaches :bound?" without reading every method.

A Crank module answers that question by structure. Each handle/3 clause declares one transition: this event, in this state, produces this outcome. The set of clauses IS the specification. It reads top to bottom like a decision table.

Coordinating multiple state machines

When multiple state machines need to coordinate -- an order triggers payment, payment triggers fulfillment, fulfillment triggers shipping -- that coordination is itself a state machine.

In domain-driven design, this pattern is called a saga (sometimes called a process manager): a long-running coordination sequence across multiple independent state machines, where each step depends on the outcome of the previous one.

A saga has states (waiting for payment, waiting for fulfillment, waiting for shipment), events (payment succeeded, fulfillment completed, shipment confirmed), and transitions (when payment succeeds, request fulfillment). That's a Crank module.

The saga doesn't contain the business logic of payment or fulfillment. It orchestrates them. Each step sends an event to another state machine and waits for the response:

def handle(:payment_confirmed, :awaiting_payment, data) do
  {:next_state, :awaiting_fulfillment, data, [{:next_event, :internal, :request_fulfillment}]}
end

def handle(:fulfillment_complete, :awaiting_fulfillment, data) do
  {:next_state, :awaiting_shipment, data}
end

State machines all the way down. The domain objects are state machines. The coordination between them is a state machine. The pattern scales because the abstraction is the same at every level.

Testing machines that interact

A common objection to pure state machines: "Sure, one machine in isolation is easy to test. But my real system has an order machine that triggers a payment machine that triggers a fulfillment machine. You can't test that without processes."

You can. The interaction between two machines is a function over two structs. Crank both of them in one test, assert on both:

test "payment confirmation advances the order and starts fulfillment" do
  order   = Crank.new(MyApp.Order)   |> Crank.crank(:submit)
  payment = Crank.new(MyApp.Payment) |> Crank.crank({:charge, order.data.total})

  # Payment succeeded -> tell the order
  assert payment.state == :confirmed
  order = Crank.crank(order, {:payment_confirmed, payment.data.txn_id})

  assert order.state == :awaiting_fulfillment
  assert order.effects == [{:next_event, :internal, :request_fulfillment}]
end

Two machines. One test. No processes, no mailboxes, no start_link, no sleeping, no eventually helpers. The interaction between them is just function calls on plain structs -- the output of one becomes the input of the next. If a third machine joins the dance, add a third struct to the test. The pattern doesn't change.

Interactions mediated by effects work the same way. When one machine's handle/3 returns [{:next_event, ...}] for another machine, that effect sits in machine.effects as inert data. Tests assert on it directly. A small reducer in the test crank-feeds effects from one machine into the next:

defp relay(source, target) do
  Enum.reduce(source.effects, target, fn
    {:next_event, _type, event}, acc -> Crank.crank(acc, event)
    _other, acc -> acc
  end)
end

Four lines. That's the whole multi-machine testing infrastructure. The existence of this function is why "pure" doesn't mean "single machine only."

What the process adds

Crank.Server adds what pure functions can't provide:

State-dependent timeouts. "If the machine is in :dispensing, fire a jam timeout after 5 seconds. If it's in :accepting, fire an inactivity timeout after 60 seconds." GenServer has one timeout mechanism. gen_statem has per-state timeouts.

State enter callbacks. "Every time the machine enters :dispensing, emit telemetry and log it." GenServer doesn't have enter callbacks.

Effect inspection. When a callback returns [{:state_timeout, 5_000, :jam_timeout}], pure code stores it in machine.effects as inert data. Tests can assert on exactly what effects a transition would produce without executing them. gen_statem executes effects immediately -- there's no way to inspect intent separately from execution.

Pure testing at scale. Crank's test suite runs 26 properties at 10,000 iterations each -- roughly 100 million random event sequences in ~20 seconds. No start_link/stop per iteration. Pure functions compose with StreamData trivially; processes don't.

Struct-per-state: making illegal states unrepresentable

The standard Elixir approach uses one struct with a :status atom and every field present in every state:

%VendingMachine{status: :dispensing, balance: 100, selection: "A3", change: nil, error: nil}
# change shouldn't exist here. error shouldn't exist here.
# But nothing prevents it.

This is what domain-driven design calls an anemic domain model -- the shape doesn't encode the rules. Any field is accessible in any state.

Crank supports an alternative: each state is its own struct. The struct defines exactly what data exists in that state. No optional fields, no "only set when the state is X" comments:

defmodule Idle,         do: defstruct []
defmodule Accepting,    do: defstruct [:balance]
defmodule Dispensing,   do: defstruct [:balance, :selection]
defmodule MakingChange, do: defstruct [:change]
defmodule OutOfStock,   do: defstruct []

A %Dispensing{} can't have a change field because the struct doesn't define one. Try %Dispensing{change: 5} and the compiler rejects it. The shape of the data enforces the rules of the state.

This works in Crank because Crank.Machine.state is term() -- atoms, structs, tagged tuples are all valid states. Pattern matching on the struct type gives the state and its data in one destructure:

def handle({:select, item}, %Accepting{balance: bal}, data) when bal >= data.price do
  {:next_state, %Dispensing{balance: bal, selection: item}, data}
end

State-specific data lives in the struct. Cross-cutting concerns (price, stock count, machine location) live in data. Elixir structs are immutable -- %Accepting{balance: 25} and %Accepting{balance: 50} are two different values. That's a state change. Use {:next_state, ...}. :keep_state means the state is literally the same value -- only data changed. This matters because {:next_state, ...} triggers on_enter/3 and :keep_state does not.

The type annotations are written for Elixir's set-theoretic type system (introduced in v1.17), which lets the compiler reason about union types and warn when a function doesn't handle all variants:

@type state :: Idle.t() | Accepting.t() | Dispensing.t() | MakingChange.t() | OutOfStock.t()

When the compiler can check this (expected mid-2026+), unhandled state variants will produce compiler warnings with zero code changes. Until then, property tests enforce the same guarantee dynamically -- see Crank.Examples.Submission for the full example.

Telemetry

Crank.Server emits a [:crank, :transition] event on every state change. Telemetry (Erlang's standard library for emitting observable events from running code) lets adapters react to transitions without the domain model knowing they exist:

%{
  module: MyApp.VendingMachine,
  from: :idle,             # nil on initial enter
  to: :accepting,
  event: {:coin, 25},      # nil on enter
  data: %{price: 75, balance: 25, stock: 10}
}

Attach handlers for persistence, notifications, audit logging, PubSub -- see the Hexagonal Architecture guide for patterns.

Persistence

%Crank.Machine{} is a plain immutable struct. Persisting it is writing a map; restoring it is reading one. There are three common strategies, and Crank supports all of them with the same small set of primitives.

Snapshot-per-transition

Write the latest state and data after every transition. On restore, read the latest row.

Writing -- attach a telemetry handler that snapshots the machine data from the transition event:

:telemetry.attach(
  "snapshot-writer",
  [:crank, :transition],
  fn _event, _measurements, %{module: mod, to: state, data: data}, _config ->
    MyApp.Repo.upsert_snapshot(%{module: mod, state: state, data: data})
  end,
  nil
)

Restoring -- load the row and hand it to from_snapshot/1 (pure) or start_from_snapshot/2 (supervised):

snapshot = MyApp.Repo.load_snapshot(order_id)

# Pure mode -- no process
machine = Crank.from_snapshot(snapshot)

# Supervised process -- resumes without calling init/1
{:ok, pid} = Crank.Server.start_from_snapshot(snapshot)

Resumed machines do not fire on_enter/3. The machine is resuming, not entering a state for the first time.

Use this when you only need the current state, not the history.

Event sourcing

Write every event to an append-only log. On restore, replay the events through Crank.crank/2 to rebuild the machine.

Writing -- attach a telemetry handler that appends the event to a log:

:telemetry.attach(
  "event-log-writer",
  [:crank, :transition],
  fn _event, _measurements, %{module: mod, event: event}, _config ->
    MyApp.Repo.append_event(%{module: mod, event: event, at: DateTime.utc_now()})
  end,
  nil
)

Restoring -- load the events and fold them through Crank.crank/2:

events = MyApp.Repo.load_events(order_id)

machine =
  MyApp.Order
  |> Crank.new(order_id: order_id)
  |> (fn m -> Enum.reduce(events, m, &Crank.crank(&2, &1)) end).()

Replay starts from whatever init/1 returns. If init/1 has side effects, they fire on every replay.

Use this when audit or time travel matters, or when you want to derive new projections from history later.

Hybrid

Write both -- snapshots every N events, full event log always. On restore, Crank.from_snapshot/1 on the latest snapshot, then Enum.reduce the events newer than the snapshot's timestamp. Commanded and EventStoreDB use this pattern. A machine with a million events restores in one snapshot read plus a few event reads. The cost: two writes per transition, and your adapter owns the case where one write succeeds and the other fails.

Schema migration

Snapshots are raw data. If your state or data shape changes between versions, you are responsible for migrating old snapshots. Event logs degrade more gracefully, because you can replay old events through new code.

Design principles

• Pure core, effectful shell (sometimes called functional core, imperative shell). Domain logic is pure data transformation -- same input, same output, no side effects. Side effects live at the boundary. This is hexagonal architecture -- the architecture makes the wrong thing impossible, not merely discouraged.
• No magic. Crank passes gen_statem types and return values through unchanged. Learning gen_statem is learning Crank.
• No hidden state. No states/0 callback, no registered names, no catch-all defaults. Function clauses declare the machine.
• Let it crash. Unhandled events are bugs. Crank surfaces them immediately.
• Auditable. ~400 lines. Every line of Crank can be read in one sitting and verified. No framework, just a library.

See DESIGN.md for the full specification and rationale behind every decision.

Installation

def deps do
  [
    {:crank, "~> 0.2.0"}
  ]
end

Documentation

• DESIGN.md -- Full specification and design rationale
• Hexagonal Architecture guide -- Integration patterns for persistence, notifications, and audit logging
• CHANGELOG.md -- Version history

License

MIT
