AccessGrid is an Elixir SDK for interacting with the AccessGrid.com API. This SDK provides a simple interface for managing NFC key cards, card templates, landing pages, credential profiles, webhooks, HID Origo organizations, and ledger items. Full docs at https://www.accessgrid.com/docs.

Installation
Configuration
Quick Start
API Reference
Utilities
Error Handling
Testing
Security
Contributing
Development
License

Installation

Add accessgrid to your list of dependencies in mix.exs:

def deps do
  [
    {:accessgrid, "~> 0.1.0"}
  ]
end

Configuration

The SDK reads credentials from your application config. Add them in config/runtime.exs so environment variables are picked up at boot:

# config/runtime.exs
import Config

config :accessgrid,
  account_id: System.get_env("ACCESSGRID_ACCOUNT_ID"),
  api_secret: System.get_env("ACCESSGRID_API_SECRET")

For static values (set at compile time) use config/config.exs instead. Either file works — the SDK doesn't care where the config came from.

With credentials in config, every SDK call resolves them automatically:

{:ok, card} = AccessGrid.AccessPasses.get("card_id")

This is the default path for single-tenant apps.

Using a custom client

For multi-tenant scenarios, testing, or scripted operations against multiple accounts, pass credentials explicitly via AccessGrid.Client.new/1:

client = AccessGrid.Client.new(
  account_id: "your_account_id",
  api_secret: "your_api_secret"
)

{:ok, card} = AccessGrid.AccessPasses.get("card_id", client: client)

Every SDK function accepts client: as an option; when omitted, it falls back to the project config.

Quick Start

# Issue a new card
{:ok, card} = AccessGrid.AccessPasses.issue(%{
  card_template_id: "template_id",
  full_name: "Employee Name",
  email: "employee@company.com"
})

IO.puts("Install URL: #{card.install_url}")

API Reference

Access passes

Issue a new card

{:ok, card} = AccessGrid.AccessPasses.issue(%{
  card_template_id: "template_id",
  employee_id: "123456789",
  card_number: "16187",
  site_code: "100",
  full_name: "Employee Name",
  email: "employee@yourwebsite.com",
  phone_number: "+19547212241",
  classification: "full_time",
  start_date: "2025-01-31T22:46:25.601Z",
  expiration_date: "2025-04-30T22:46:25.601Z",
  employee_photo: AccessGrid.Utils.base64_file!("path/to/photo.png"),
  metadata: %{department: "Engineering"}
})

IO.puts("Install URL: #{card.install_url}")

Get a card

{:ok, card} = AccessGrid.AccessPasses.get("card_id")

IO.puts("Card ID: #{card.id}")
IO.puts("State: #{card.state}")
IO.puts("Full Name: #{card.full_name}")
IO.puts("Install URL: #{card.install_url}")
IO.puts("Expiration Date: #{card.expiration_date}")
IO.puts("Card Number: #{card.card_number}")
IO.puts("Site Code: #{card.site_code}")
IO.puts("Devices: #{length(card.devices)}")
IO.puts("Metadata: #{inspect(card.metadata)}")

Update a card

{:ok, card} = AccessGrid.AccessPasses.update("card_id", %{
  employee_id: "987654321",
  full_name: "Updated Employee Name",
  classification: "contractor",
  expiration_date: "2025-02-22T21:04:03.664Z"
})

List cards

# List all cards for a template
{:ok, cards} = AccessGrid.AccessPasses.list("template_id")

# List cards filtered by state
{:ok, active_cards} = AccessGrid.AccessPasses.list("template_id", state: "active")

Manage card states

# Suspend a card
{:ok, card} = AccessGrid.AccessPasses.suspend("card_id")

# Resume a card
{:ok, card} = AccessGrid.AccessPasses.resume("card_id")

# Unlink a card
{:ok, card} = AccessGrid.AccessPasses.unlink("card_id")

# Delete a card
{:ok, card} = AccessGrid.AccessPasses.delete("card_id")

Card templates

Create a template

All template fields are flat — no design: or support_info: wrappers. Pair image params with AccessGrid.Utils.base64_file!/1.

{:ok, result} = AccessGrid.Console.create_template(%{
  name: "Employee NFC key",
  platform: "apple",
  use_case: "corporate_id",
  protocol: "desfire",
  allow_on_multiple_devices: true,
  watch_count: 2,
  iphone_count: 3,
  background_color: "#FFFFFF",
  label_color: "#000000",
  label_secondary_color: "#333333",
  background: AccessGrid.Utils.base64_file!("path/to/background.png"),
  logo: AccessGrid.Utils.base64_file!("path/to/logo.png"),
  icon: AccessGrid.Utils.base64_file!("path/to/icon.png"),
  support_url: "https://help.yourcompany.com",
  support_phone_number: "+1-555-123-4567",
  support_email: "support@yourcompany.com",
  privacy_policy_url: "https://yourcompany.com/privacy",
  terms_and_conditions_url: "https://yourcompany.com/terms",
  credential_profiles: ["cp_ex_id_1"],
  landing_pages: ["lp_ex_id_1"],
  metadata: %{version: "1.0"}
})

IO.puts("Template ID: #{result.id}")
IO.puts("Estimated Publishing: #{result.estimated_publishing_date}")

Update a template

{:ok, result} = AccessGrid.Console.update_template("template_id", %{
  name: "Updated Employee NFC key",
  watch_count: 3,
  support_url: "https://help.yourcompany.com",
  support_email: "newsupport@yourcompany.com"
})

Read a template

The same endpoint serves both single templates and template pairs. Pattern match on the returned struct to tell them apart.

case AccessGrid.Console.read_template("template_id") do
  {:ok, %AccessGrid.CardTemplate{} = template} ->
    IO.puts("Name: #{template.name}")
    IO.puts("Platform: #{template.platform}")
    IO.puts("Background color: #{template.background_color}")
    IO.puts("Support email: #{template.support_email}")
    IO.puts("Watch count: #{template.watch_count}")
    IO.puts("Allow on multiple devices: #{template.allow_on_multiple_devices}")
    IO.puts("Issued keys: #{template.issued_keys_count}")
    IO.puts("Active keys: #{template.active_keys_count}")
    IO.puts("Credential profiles: #{inspect(template.credential_profiles)}")
    IO.puts("Landing pages: #{inspect(template.landing_pages)}")

  {:ok, %AccessGrid.CardTemplatePair{} = pair} ->
    IO.puts("Pair: #{pair.name}")
    Enum.each(pair.templates, fn t -> IO.puts(" - #{t.platform}: #{t.id}") end)
end

Get event logs

{:ok, events, pagination} = AccessGrid.Console.get_logs("template_id",
  page: 1,
  per_page: 50,
  filters: %{
    device: "mobile",
    start_date: "2025-01-01T00:00:00Z",
    end_date: "2025-01-31T23:59:59Z",
    event_type: "access_pass.installed"
  }
)

Enum.each(events, fn event ->
  IO.puts("#{event.created_at}: #{event.event}")
end)

IO.puts("Page #{pagination["current_page"]} of #{pagination["total_pages"]}")

iOS preflight

Returns the Apple In-App Provisioning preflight bundle for an access pass.

{:ok, preflight} = AccessGrid.Console.ios_preflight(
  "template_id",
  %{access_pass_ex_id: "ap_abc123"}
)

IO.puts("Provisioning credential: #{preflight.provisioning_credential_identifier}")
IO.puts("Sharing instance: #{preflight.sharing_instance_identifier}")
IO.puts("Card template: #{preflight.card_template_identifier}")
IO.puts("Environment: #{preflight.environment_identifier}")

Publish a template

For Android+SEOS templates, Rails also syncs the template to the HID portal. If the sync fails the template rolls back to draft and the call returns {:error, :validation_failed, _}.

{:ok, result} = AccessGrid.Console.publish_template("template_id")

IO.puts("Template #{result.id} status: #{result.status}")
# status is one of: "publishing" (already in flight), "in-review" (Apple
# queued), or "ready" (Android immediate)

Reveal SmartTap credentials

Returns the template's smart_tap_key encrypted with your ephemeral public key. Each request needs a fresh keypair (Rails enforces single-use by fingerprint, and rate-limits to 1 per minute per account).

# Generate an ephemeral EC keypair (e.g. via openssl)
{pub_pem, 0} = System.cmd("openssl", ["ec", "-in", "priv.pem", "-pubout"])

{:ok, reveal} = AccessGrid.Console.reveal_smart_tap(
  "template_id",
  %{client_public_key: pub_pem}
)

IO.puts("Key version: #{reveal.key_version}")
IO.puts("Collector ID: #{reveal.collector_id}")
IO.puts("Fingerprint: #{reveal.fingerprint}")
IO.inspect(reveal.encrypted_private_key, label: "envelope")
# encrypted_private_key is a map: %{"alg" => ..., "ephemeral_public_key" => ..., "iv" => ..., "ciphertext" => ..., "tag" => ...}
# Decrypt with your matching private key.

If you retry with the same public key, the call returns {:error, :conflict, _} (single-use enforcement).

Card template pairs

List template pairs

{:ok, pairs, pagination} = AccessGrid.Console.list_card_template_pairs(
  page: 1,
  per_page: 25
)

Enum.each(pairs, fn pair ->
  IO.puts("#{pair.name}: iOS=#{pair.ios_template.id}, Android=#{pair.android_template.id}")
end)

Create a template pair

Pairs two existing card templates (one Apple, one Android) for cross-platform issuance. Both templates must be status: "ready" and use a compatible protocol combination (both SEOS, or Apple-DESFire + Android-SmartTap).

{:ok, pair} = AccessGrid.Console.create_card_template_pair(%{
  name: "Cross-Platform Employee Badge",
  apple_card_template_id: "tpl_apple_xyz",
  google_card_template_id: "tpl_android_xyz"
})

IO.puts("Pair ID: #{pair.id}")

Landing pages

List landing pages

{:ok, pages} = AccessGrid.Console.list_landing_pages()

Enum.each(pages, fn page -> IO.puts("#{page.id}: #{page.name} (#{page.kind})") end)

Create a landing page

{:ok, page} = AccessGrid.Console.create_landing_page(%{
  name: "Lobby Access",
  kind: "universal",
  additional_text: "Welcome — install your pass on your phone",
  bg_color: "#1a1a1a",
  allow_immediate_download: true,
  logo: AccessGrid.Utils.base64_file!("path/to/logo.png")
})

IO.puts("Landing page ID: #{page.id}")
IO.puts("Logo URL: #{page.logo_url}")

Update a landing page

kind is immutable after creation — passing a different value yields a {:error, :validation_failed, _}. Other fields can be updated freely.

{:ok, page} = AccessGrid.Console.update_landing_page("lp_ex_id_1", %{
  name: "Lobby Access (renamed)",
  password: "letmein",
  is_2fa_enabled: true
})

Credential profiles

List credential profiles

{:ok, profiles} = AccessGrid.Console.list_credential_profiles()

Enum.each(profiles, fn p -> IO.puts("#{p.id}: #{p.name} (aid=#{p.aid})") end)

Create a credential profile

Each app has a fixed required key count: KEY-ID-main and KEY-ID-alt need 2 keys, ag_main needs 3. Passing the wrong number yields {:error, :validation_failed, _}.

{:ok, profile} = AccessGrid.Console.create_credential_profile(%{
  name: "Office Reader",
  app_name: "KEY-ID-main",
  keys: [
    %{value: "00112233445566778899AABBCCDDEEFF"},
    %{value: "FFEEDDCCBBAA99887766554433221100", keys_diversified: true}
  ]
})

IO.puts("Profile ID: #{profile.id}")
IO.puts("AID: #{profile.aid}")
IO.inspect(profile.keys, label: "keys")
IO.inspect(profile.files, label: "files")

Webhooks

List webhooks

{:ok, webhooks, pagination} = AccessGrid.Console.list_webhooks(page: 1, per_page: 50)

Enum.each(webhooks, fn wh ->
  IO.puts("#{wh.id}: #{wh.name} (#{wh.auth_method}) → #{wh.url}")
end)

Create a webhook

auth_method is either "bearer_token" (default) or "mtls". Sensitive fields appear on the create response only once:

bearer_token:private_key is returned — store it immediately, it cannot be retrieved later.
mtls:client_cert (PEM) and cert_expires_at are returned.

{:ok, webhook} = AccessGrid.Console.create_webhook(%{
  name: "Production",
  url: "https://example.com/hooks",
  subscribed_events: ["ag.access_pass.issued", "ag.card_template.created"],
  auth_method: "bearer_token"
})

IO.puts("Webhook ID: #{webhook.id}")
IO.puts("Private key (store now — not retrievable later): #{webhook.private_key}")

Delete a webhook

Returns :ok (flat, not {:ok, _}) on success since Rails returns 204 No Content.

:ok = AccessGrid.Console.delete_webhook("webhook_id")

HID orgs

List HID orgs

{:ok, orgs} = AccessGrid.Console.list_hid_orgs()

Enum.each(orgs, fn org -> IO.puts("#{org.id}: #{org.name} (status=#{org.status})") end)

Create a HID org

Idempotent on the derived slug — if an org with the same slug already exists, Rails returns the existing record with 200 instead of creating a new one.

{:ok, org} = AccessGrid.Console.create_hid_org(%{
  name: "Acme Corp",
  full_address: "1 Acme Plaza, NY 10001",
  phone: "+1-555-0100",
  first_name: "Wile E.",
  last_name: "Coyote"
})

IO.puts("HID org ID: #{org.id}")
IO.puts("Slug: #{org.slug}")

Activate a HID org

Completes registration with the HID portal using the org's registered email and the customer's HID portal password.

{:ok, org} = AccessGrid.Console.activate_hid_org(%{
  email: "admin@acme.com",
  password: "hid-portal-password"
})

IO.puts("Status: #{org.status}")

Rails may return extra fields (already_completed: true if the org is already activated, job_queued: true if a registration job is in flight) — these aren't surfaced on the struct. Inspect org.status for the current state.

Ledger items

List ledger items

{:ok, items, pagination} = AccessGrid.Console.list_ledger_items(
  page: 1,
  per_page: 50,
  start_date: "2026-01-01T00:00:00Z",
  end_date: "2026-12-31T23:59:59Z"
)

Enum.each(items, fn item ->
  IO.puts("#{item.created_at}: #{item.kind} $#{item.amount}")
  if item.access_pass, do: IO.puts("  pass: #{item.access_pass.full_name}")
end)

Utilities

Encode an image as base64

AccessGrid.Utils.base64_file!/1 reads a file from the local filesystem and returns its contents Base64-encoded as a string — suitable for any of the SDK's image-accepting params (background, logo, icon on create_template; logo on create_landing_page; employee_photo on AccessPasses.issue).

# Bang variant — raises File.Error if the path doesn't exist
b64 = AccessGrid.Utils.base64_file!("path/to/badge.png")

# Tuple variant — returns {:ok, encoded} or {:error, posix_reason}
case AccessGrid.Utils.base64_file("path/to/badge.png") do
  {:ok, b64} -> # ...
  {:error, :enoent} -> # file missing
end

The helper does not validate the file's contents — Rails enforces format and size limits (PNG/JPEG, 10MB max) and returns clear errors. No URL support: if you have an image at a URL, fetch it with your own HTTP client and Base.encode64/1 the bytes.

Error Handling

All functions return {:ok, result} (or {:ok, list, pagination} for paginated lists, or :ok for delete_webhook) on success, or {:error, reason, failure} on failure:

case AccessGrid.AccessPasses.get("card_id") do
  {:ok, card} ->
    IO.puts("Found card: #{card.full_name}")

  {:error, :not_found, _failure} ->
    IO.puts("Card not found")

  {:error, :unauthorized, _failure} ->
    IO.puts("Invalid credentials")

  {:error, :validation_failed, failure} ->
    IO.puts("Validation error: #{inspect(failure.body_decoded)}")

  {:error, reason, _failure} ->
    IO.puts("Request failed: #{reason}")
end

Error reasons include:

:unauthorized - Invalid credentials (401)
:forbidden - Access denied (403)
:not_found - Resource not found (404)
:conflict - Conflict with current resource state (409) — e.g. reveal_smart_tap retried with a pubkey that's already been used
:validation_failed - Invalid parameters (422)
:rate_limited - Too many requests (429)
:timeout - Request timeout
:server_error - Server error (5xx)
:request_failed - Other failures
:missing_required - Local validation caught a missing/blank required field before any HTTP call. The third element is a non-empty list of atom field names (e.g. [:template_id, :access_pass_ex_id]) — not an HttpFailure. See AccessGrid.Params.

The third element (failure) is an AccessGrid.HttpFailure struct with additional context like status code and response body, except for :missing_required (see above — that variant carries a list of field-name atoms instead).

Testing

See the Testing Guide for detailed examples of how to mock AccessGrid in your tests.

Security

The SDK automatically handles:

Request signing using HMAC-SHA256
Secure payload encoding
Authentication headers
HTTPS communication

Never expose your api_secret in client-side code. Always use environment variables or a secure configuration management system.

Contributing

Bug reports and pull requests are welcome on GitHub.

Development

Requirements

Elixir 1.17 or higher
OTP 26 or higher

Note: A .tool-versions file exists. asdf users can install these requirements with asdf install from the project root.

Initial setup

After checking out the repo, run the doctor script to verify your environment:

bin/dev/doctor

Run tests:

mix test

Run all checks (format, credo, dialyzer):

bin/dev/audit

License

The package is available as open source under the terms of the MIT License.

Contents
